Atlas Copco Service Kit Selection – If your model is not listed, let us find the right kit!
Use the Compressor Now Atlas Copco Service Kit Selection Tools. Find the right Atlas Copco Air Filter, Atlas Copco Oil Filter & Atlas Copco Separator. All reference sheets are for reference only and are not a guarantee that it is the correct part for your machine, always consult the manufacturer parts manual.Â
Atlas Copco Air Filter
Atlas Copco Oil Filter
Atlas Copco Separator
| Model | Serial # | Air Filter |
|---|---|---|
| GA5 | Â | 1503019000 |
| GA5 | Starting 1998 | 1613900100 |
| GA5 | Starting 119500 | 1613900100 |
| GA5 | Starting 145000 | 1613900100 |
| GA5 C | Starting 130000 | 1613900100 |
| GA5 C | Starting 145000 | 1613900100 |
| GA5 VSD | Starting 700000 | 1613900100 |
| GA7 | Â | 1503019000 |
| GA7 | Starting 119500 | 1613900100 |
| GA7 | Starting 145000 | 1613900100 |
| GA7 C | Starting 130000 | 1613900100 |
| GA7 C | Starting 145000 | 1613900100 |
| GA7 VSD | Starting 700000 | 1613900100 |
| GA7 VSD+ | Â | 1613872000 |
| GA10 | Â | 1503019000 |
| GA10 | Starting 119500 | 1613900100 |
| GA10 | Starting 145000 | 1613900100 |
| GA11 | Â | 2903101200 |
| GA11 | Starting 1993 | 2903101200 |
| GA11 | 1994 Through 217791 | 2903101200 |
| GA11 | 1995 Starting 217792 | 2903101200 |
| GA11 | Starting 246349 | 1613872000 |
| GA11 C | Â | 1613900100 |
| GA11 C | Starting 119500 | 1613900100 |
| GA11 C | Starting 145000 | 1613900100 |
| GA11 C | Starting 255000 | 1613872000 |
| GA11 C | Starting 268500 | 1613872000 |
| GA11 PLUS | Starting 810000 | 1613872000 |
| GA11 VSD | Starting 700000 | 1613900100 |
| GA11 VSD+ | Â | 1613872000 |
| GA15 | Â | 2903101200 |
| GA15 | Starting 1993 | 2903101200 |
| GA15 | 1994 Through 217791 | 2903101200 |
| GA15 | 1995 Starting 217792 | 2903101200 |
| GA15 | Starting 2000 | 1613872000 |
| GA15 | Starting 246349 | 1613872000 |
| GA15 C | Starting 255000 | 1613872000 |
| GA15 C | Starting 268500 | 1613872000 |
| GA15 PLUS | Starting 810000 | 1613872000 |
| GA15 VSD | Starting 700000 | 1613872000 |
| GA15 VSD+ | Â | 1613872000 |
| GA18 | Â | 2903101200 |
| GA18 | Starting 1993 | 2903101200 |
| GA18 | 1994 Through 217791 | 2903101200 |
| GA18 | 1995 Starting 217792 | 2903101200 |
| GA18 | Starting 2000 | 1613872000 |
| GA18 | Starting 246349 | 1613872000 |
| GA18 C | Starting 255000 | 1613872000 |
| GA18 C | Starting 268500 | 1613872000 |
| GA18 VSD | Â | 1613872000 |
| GA18 PLUS | Starting 810000 | 1613872000 |
| GA22 | Â | 2903101200 |
| GA22 | Starting 1993 | 2903101200 |
| GA22 | 1994 Through 217791 | 2903101200 |
| GA22 | 1995 Starting 217792 | 2903101200 |
| GA22 | Starting 2000 | 1613872000 |
| GA22 | Starting 246349 | 1613872000 |
| GA22 C | Starting 255000 | 1613872000 |
| GA22 C | Starting 268500 | 1613872000 |
| GA22 PLUS | Starting 268500 | 1613872000 |
| GA22 PLUS | Starting 810000 | 1613872000 |
| GA22 VSD | 297500-420963 | 1613872000 |
| GA26 PLUS | Starting 810000 | 1613872000 |
| GA30 | Starting 1994 | 2903740700 |
| GA30 | Starting 315330 | 2903740700 |
| GA30 | 1998 Starting 360000 | 2903740700 |
| GA30 | Starting 810000 | 1613872000 |
| GA30 C | Starting 2000 | 1613872000 |
| GA30 C | Starting 255000 | 1613872000 |
| GA30 C | Starting 268500 | 1613872000 |
| GA30 PLUS | Starting 507438 | 1613740800 |
| GA30 PLUS | 2006 Starting 591000 | 2903740700 |
| GA30 VSD | Â | 1613740800 |
| GA37 | Starting 1994 | 2903740700 |
| GA37 | Starting 315330 | 2903740700 |
| GA37 | 1998 Starting 360000 | 2903740700 |
| GA37 | 2006 Starting 591000 | 2903740700 |
| GA37 – 7.5 Bar | Â | 1613740800 |
| GA37 – 10 Bar | Â | 2903740700 |
| GA37 – 13 Bar | Â | 2903740700 |
| GA37 PLUS | Starting 507438 | 1613740800 |
| GA37 VSD | Â | 1613740800 |
| GA37 VSD | Starting 572446 | 1613740800 |
| GA45 | Â | 1619284700 |
| GA45 | Starting 1994 | 1619284700 |
| GA45 | Starting 1995 | 1613740800 |
| GA45 | 1994 Through 315329 | 1619284700 |
| GA45 | Starting 315330 | 1613740800 |
| GA45 | 1998 Starting 360000 | 1613740800 |
| GA45 | 2006 Starting 591000 | 2903740700 |
| GA45 – 7.5 Bar | Â | 1613740800 |
| GA45 – 10 Bar | Â | 1613740800 |
| GA45 – 13 Bar | Â | 2903740700 |
| GA45 PLUS | Starting 507438 | 1613740800 |
| GA45 VSD | Starting 572446 | 1613740800 |
| GA50 | 1998 Starting 350000 | 1613740800 |
| GA50 VSD | Â | 1613740800 |
| GA55 | Â | 1619279800 |
| GA55 | Starting 1995 | 1613740800 |
| GA55 | 1996 Starting 460001 | 1613740800 |
| GA55 | Starting 2000 | 1613950100 |
| GA55 | Starting 507438 | 1622185501 |
| GA55 C | Â | 1613740800 |
| GA55 C | Starting 471000 | 1613950100 |
| GA55 PLUS | Starting 2005 | 1613950300 |
| GA55 VSD | Starting 572446 | 1622185501 |
| GA75 | Â | 1613950100 |
| GA75 | Starting 1995 | 1613740800 |
| GA75 | 1996 Starting 460001 | 1613800400 |
| GA75 | Starting 2000 | 1613950300 |
| GA75 | Starting 471000 | 1613950300 |
| GA75 | Starting 507438 | 1622185501 |
| GA75 C | Starting 474000 | 1613950300 |
| GA75 PLUS | Starting 2005 | 1613950300 |
| GA75 VSD | Â | 1613950300 |
| GA75 VSD | Starting 493000 | 1613950300 |
| GA90 | Â | 1630040699 |
| GA90 | 1999 Starting 056813 | 1630040699 |
| GA90 PLUS | Starting 2005 | 1613950300 |
| GA90 | Starting 2006 | 1613950300 |
| GA90 – 5.2-5.5 Bar | Starting 2008 | 1630040899 |
| GA90 – 6.9-8.6 Bar | Starting 2008 | 1630040899 |
| GA90 – 10-14 Bar | Starting 2008 | 1630040899 |
| GA90 C | Â | 1613800400 |
| GA90 C | Starting 474000 | 1613950300 |
| GA90 VSD | Â | 1613950300 |
| GA90 VSD | Starting 493000 | 1613950300 |
| GA100 | Â | 2903101200 |
| GA110 | Â | 1630040699 |
| GA110 | 1999 Starting 056813 | 1630040699 |
| GA110 | Starting 2006 | 1630040699 |
| GA110 | Starting 2008 | 1630040899 |
| GA110Â – 10-14 Bar | Starting 2008 | 1630040899 |
| GA110 PLUS | Starting 2008 | 1630040899 |
| GA110 PLUSÂ 10-14 Bar | Starting 2008 | 1630040899 |
| GA111 up to 122 | Â | 2903101200 |
| GA132 | Â | 1630040699 |
| GA132 | 1999 Starting 056813 | 1630040699 |
| GA132 | Starting 2006 | 1630040699 |
| GA132 – 5.2-5.5 Bar | Starting 2008 | 1630040899 |
| GA132 – 6.9-8.6 Bar | Starting 2008 | 1630040899 |
| GA132 – 10-14 Bar | Starting 2008 | 1630040899 |
| GA160 | Â | 1630040699 |
| GA160 | 1999 Starting 056813 | 1630040699 |
| GA160 | Starting 2006 | 1630040699 |
| GA160Â – 5.2-5.5 Bar | Starting 2008 | 1630040899 |
| GA160Â – 6.9-8.6 Bar | Starting 2008 | 1630040899 |
| GA160Â – 10-14 Bar | Starting 2008 | 1630040899 |
| GA180 VSD | Â | 1630040699 |
| GA180 VSD | Starting 2006 | 1630040699 |
| GA200 | Â | 1630040699 |
| GA200 | Starting 1999 | 1630040699 |
| GA200 | Starting 2000 | 1630040699 |
| GA200 | Starting 2006 | 1630040699 |
| GA200 | Starting 2008 | 1621510700 |
| GA250 | Â | 1630040699 |
| GA250 | Â | 1619279800 |
| GA315 | Â | 1630040699 |
| GA315 | Starting 2000 | 1630040699 |
| GA315 | Starting 2006 | 1630040699 |
| GA315 VSD | Â | 1630040699 |
| GA315 VSD | Starting 2006 | 1630040699 |
| GA345 | Â | 1619284700 |
| GA355 | Â | 1619279800 |
| GA375 | Â | 1619279800 |
| GA450 | Â | 1630040699 |
| GA450 | Starting 2006 | 1630040699 |
| GA807 up to 1110 | Â | 1630040699 |
| GA1207 up to 1410 | Â | 1630040699 |
| GAH 115 | Â | 2903101200 |
| GAH 118 | Â | 2903101200 |
| GAH 122 | Â | 2903101200 |
| GAU15 up to 40 | Â | 2903101200 |
| GAU807 up to 1409 | Â | 1630040699 |
| GR110 up to 200 | Â | 1630040699 |
| GR110 up to 200 | Starting 085972 | 1630040699 |
| GR1120 | Â | 1630040699 |
| GR1520 | Â | 1630040699 |
| GX2 | Â | 1622065800 |
| GX3 | Â | 1622065800 |
| GX4 | Â | 1622065800 |
| GX5 | Â | 1613900100 |
| GX5 | New | 1622065800 |
| GX7 | Â | 1613900100 |
| GX7 | Through 619999 | 1613900100 |
| GX7 | Starting 620000 | 1613900100 |
| GX11 | Â | 1613900100 |
| GX11 | Through 619999 | 1613900100 |
| GX11 | Starting 620000 | 1613900100 |
| GX15 | Â | 1613872000 |
| GX18 | Â | 1613872000 |
| GX22 | Â | 1613872000 |
| Model | Serial # | Oil Filter |
|---|---|---|
| GA5 | Â | 2903033701 |
| GA5 | From 1998 | 1613610590 |
| GA5 | From 119500 | 1613610590 |
| GA5 | From 145000 | 2903033701 |
| GA5 C | From 130000 | 1613610590 |
| GA5 C | From 145000 | 2903033701 |
| GA5 VSD | From 700000 | 2202929550 |
| GA7 | Â | 2903033701 |
| GA7 | From 119500 | 1613610590 |
| GA7 | From 145000 | 2903033701 |
| GA7 C | From 130000 | 1613610590 |
| GA7 C | From 145000 | 2903033701 |
| GA7 VSD | From 700000 | 2202929550 |
| GA7 VSD+ | Â | 1625427450 |
| GA10 | Â | 2903033701 |
| GA10 | From 119500 | 1613610590 |
| GA10 | From 145000 | 2903033701 |
| GA11 | Â | 1613610590 |
| GA11 | From 1993 | 1613610590 |
| GA11 | 1994 Up To 217791 | 1613610590 |
| GA11 | 1995 From 217792 | 1613610590 |
| GA11 | From 246349 | 1613610590 |
| GA11 C | Â | 1613610590 |
| GA11 C | From 119500 | 1613610590 |
| GA11 C | From 145000 | 2903033701 |
| GA11 C | From 255000 | 1613610590 |
| GA11 C | From 268500 | 1613610590 |
| GA11 PLUS | From 810000 | 2903783600 |
| GA11 VSD | From 700000 | 2202929550 |
| GA11 VSD+ | Â | 1625427450 |
| GA15 | Â | 1613610590 |
| GA15 | From 1993 | 1613610590 |
| GA15 | 1994 Up To 217791 | 1613610590 |
| GA15 | 1995 From 217792 | 1613610590 |
| GA15 | From 2000 | 1613610590 |
| GA15 | From 246349 | 1613610590 |
| GA15 C | From 255000 | 1613610590 |
| GA15 C | From 268500 | 1613610590 |
| GA15 PLUS | From 810000 | 2903783600 |
| GA15 VSD | From 700000 | 2202929550 |
| GA15 VSD+ | Â | 1625427450 |
| GA18 | Â | 1613610590 |
| GA18 | From 1993 | 1613610590 |
| GA18 | 1994 Up To 217791 | 1613610590 |
| GA18 | 1995 From 217792 | 1613610590 |
| GA18 | From 2000 | 1613610590 |
| GA18 | From 246349 | 1613610590 |
| GA18 C | From 255000 | 1613610590 |
| GA18 C | From 268500 | 1613610590 |
| GA18 VSD | Â | 1613610590 |
| GA18 PLUS | From 810000 | 2903783600 |
| GA22 | Â | 1613610590 |
| GA22 | From 1993 | 1613610590 |
| GA22 | 1994 Up To 217791 | 1613610590 |
| GA22 | 1995 From 217792 | 1613610590 |
| GA22 | From 2000 | 1613610590 |
| GA22 | From 246349 | 1613610590 |
| GA22 C | From 255000 | 1613610590 |
| GA22 C | From 268500 | 1613610590 |
| GA22 PLUS | From 268500 | 1613610590 |
| GA22 PLUS | From 810000 | 2903783600 |
| GA22 VSD | 297500-420963 | 1613610590 |
| GA26 PLUS | From 810000 | 2903783600 |
| GA30 | Â | 1613610590 |
| GA30 | From 1994 | 1613610590 |
| GA30 | 1994 Up To 315329 | 1613610590 |
| GA30 | From 315330 | 1613610590 |
| GA30 | 1998 From 360000 | 1613610590 |
| GA30 | From 810000 | 2903783600 |
| GA30 C | From 2000 | 1613610590 |
| GA30 C | From 255000 | 1613610590 |
| GA30 C | From 268500 | 1613610590 |
| GA30 PLUS | From 507438 | 1630840180 |
| GA30 PLUS | 2006 From 591000 | 1630840180 |
| GA30 VSD | Â | 1613610590 |
| GA37 | Â | 1613610590 |
| GA37 | From 1994 | 1613610590 |
| GA37 | 1994 Up To 315329 | 1613610590 |
| GA37 | From 315330 | 1613610590 |
| GA37 | 1998 From 360000 | 1613610590 |
| GA37 | 2006 From 591000 | 1630840180 |
| GA37 – 7.5 Bar | Â | 1613610590 |
| GA37 – 10 Bar | Â | 1613610590 |
| GA37 – 13 Bar | Â | 1613610590 |
| GA37 PLUS | From 507438 | 1630840180 |
| GA37 VSD | Â | 1613610590 |
| GA37 VSD | From 572446 | 1630840180 |
| GA45 | Â | 1613610590 |
| GA45 | From 1994 | 1613610590 |
| GA45 | From 1995 | 1613610590 |
| GA45 | 1994 Up To 315329 | 1613610590 |
| GA45 | From 315330 | 1613610590 |
| GA45 | 1998 From 360000 | 1613610590 |
| GA45 | 2006 From 591000 | 1630840180 |
| GA45 – 7.5 Bar | Â | 1613610590 |
| GA45 – 10 Bar | Â | 1613610590 |
| GA45 – 13 Bar | Â | 1613610590 |
| GA45 PLUS | From 507438 | 1630840180 |
| GA45 VSD | FRom 572446 | 1630840180 |
| GA50 | 1998 From 350000 | 1613610590 |
| GA50 VSD | Â | 1613610590 |
| GA55 | Â | 1613610590 |
| GA55 | From 1995 | 1613610590 |
| GA55 | 1996 From 460001 | 1613610590 |
| GA55 | From 2000 | 1613610590 |
| GA55 | From 507438 | 1630840180 |
| GA55 C | Â | 1613610590 |
| GA55 C | From 471000 | 1613610590 |
| GA55 PLUS | From 2005 | 2901194402 |
| GA55 VSD | From 572446 | 1630840180 |
| GA75 | Â | 1613610590 |
| GA75 | From 1995 | 1613610590 |
| GA75 | 1996 From 460001 | 1613610590 |
| GA75 | From 2000 | 1613610590 |
| GA75 | From 471000 | 1613610590 |
| GA75 | From 507438 | 1630840180 |
| GA75 C | From 474000 | 1613610590 |
| GA75 PLUS | From 2005 | 2901194502 |
| GA75 VSD | Â | 2901194402 |
| GA75 VSD | From 493000 | 1613610590 |
| GA90 | Â | 1613610590 |
| GA90 | 1999 From 056813 | 1613610590 |
| GA90 PLUS | From 2005 | 2901194402 |
| GA90 | From 2006 | 2901194402 |
| GA90 – 5.2-5.5 Bar | From 2008 | 1621737890 |
| GA90 – 6.9-8.6 Bar | From 2008 | 1621737890 |
| GA90 – 10-14 Bar | From 2008 | 1621737890 |
| GA90 C | Â | 1613610590 |
| GA90 C | From 474000 | 1613610590 |
| GA90 VSD | Â | 2901194402 |
| GA90 VSD | From 493000 | 1613610590 |
| GA100 | Â | 1613610590 |
| GA110 | Â | 1613610590 |
| GA110 | 1999 From 056813 | 1613610590 |
| GA110 | From 2006 | 1613610590 |
| GA110 | From 2008 | 1621737890 |
| GA110Â – 10-14 Bar | From 2008 | 1621737890 |
| GA110 PLUS | From 2008 | 1621737890 |
| GA110 PLUSÂ 10-14 Bar | From 2008 | 1621737890 |
| GA111 up to 122 | Â | 1613610590 |
| GA132 | Â | 1613610590 |
| GA132 | 1999 From 056813 | 1613610590 |
| GA132 | From 2006 | 1613610590 |
| GA132 – 5.2-5.5 Bar | From 2008 | 1621737890 |
| GA132 – 6.9-8.6 Bar | From 2008 | 1621737890 |
| GA132 – 10-14 Bar | From 2008 | 1621737890 |
| GA160 | Â | 1613610590 |
| GA160 | 1999 From 056813 | 1613610590 |
| GA160 | From 2006 | 1613610590 |
| GA160Â – 5.2-5.5 Bar | From 2008 | 1621737890 |
| GA160Â – 6.9-8.6 Bar | From 2008 | 1621737890 |
| GA160Â – 10-14 Bar | From 2008 | 1621737890 |
| GA180 VSD | Â | 1613610590 |
| GA180 VSD | From 2006 | 1613610590 |
| GA200 | Â | 1614727399 |
| GA200 | From 1999 | 1613610590 |
| GA200 | From 2000 | 1614727399 |
| GA200 | From 2006 | 1614727399 |
| GA200 | From 2008 | 1614727399 |
| GA207 up to 210 | Â | 1613610590 |
| GA230 | Â | 1613610590 |
| GA237 | Â | 1613610590 |
| GA250 | Â | 1614727399 |
| GA250 | Â | 1614806599 |
| GA307 up to 310 | Â | 1613610590 |
| GA315 | Â | 1614727399 |
| GA315 | From 2000 | 1614727399 |
| GA315 | From 2006 | 1614727399 |
| GA315 VSD | Â | 1614727399 |
| GA315 VSD | From 2006 | 1614727399 |
| GA345 | Â | 1613610590 |
| GA355 | Â | 1613610590 |
| GA375 | Â | 1613610590 |
| GA407 up to 410 | Â | 1613610590 |
| GA450 | Â | 1614727399 |
| GA450 | From 2006 | 1613610590 |
| GA507 up to 510 | Â | 1613610590 |
| GA607 upto 710 | Â | 1613610590 |
| GA807 up to 1110 | Â | 1613610590 |
| GA1207 up to 1410 | Â | 1613610590 |
| GAH 115 | Â | 1613610590 |
| GAH 118 | Â | 1613610590 |
| GAH 122 | Â | 1613610590 |
| GAU15 up to 40 | Â | 1310250762 |
| GAU307 up to 509 | Â | 1613610590 |
| GAU607 up to 709 | Â | 1613610590 |
| GAU807 up to 1409 | Â | 1613610590 |
| GR110 up to 200 | Â | 1202804093 |
| GR110 up to 200 | From 085972 | 1202804093 |
| GR620 | Â | 1202804093 |
| GR1120 | Â | 1202804093 |
| GR1520 | Â | 1202804093 |
| GX2 | Â | 2903033701 |
| GX3 | Â | 2903033701 |
| GX4 | Â | 2903033701 |
| GX5 | Â | 1613610590 |
| GX5 | New | 2903033701 |
| GX7 | Â | 1613610590 |
| GX7 | Up to 619999 | 2903033701 |
| GX7 | From 620000 | 1613610590 |
| GX11 | Â | 1613610590 |
| GX11 | Up to 619999 | 2903033701 |
| GX11 | From 620000 | 1613610590 |
| GX15 | Â | 1613610590 |
| GX18 | Â | 1613610590 |
| GX22 | Â | 1613610590 |
| Model | Serial # | Separator |
|---|---|---|
| GA5 | Â | 1513005801 |
| GA5 | From 1998 | 2901052300 |
| GA5 | From 119500 | 2901052300 |
| GA5 | From 145000 | 2901052300 |
| GA5 C | From 130000 | 2901052300 |
| GA5 C | From 145000 | 2903087100 |
| GA5 VSD | From 700000 | 2202929450 |
| GA7 | Â | 1513005801 |
| GA7 | From 119500 | 2901052300 |
| GA7 | From 145000 | 2901052300 |
| GA7 C | From 130000 | 2901052300 |
| GA7 C | From 145000 | 2903087100 |
| GA7 VSD | From 700000 | 2202929450 |
| GA7 VSD+ | Â | 2202929450 |
| GA10 | Â | 1513005801 |
| GA10 | From 119500 | 2901052300 |
| GA10 | From 145000 | 2901052300 |
| GA11 | Â | 1612386901 |
| GA11 | From 1993 | 2901000401 |
| GA11 | 1994 Up To 217791 | 2901000401 |
| GA11 | 1995 From 217792 | 2901034301 |
| GA11 | From 246349 | 2901034301 |
| GA11 C | Â | 2901034301 |
| GA11 C | From 119500 | 2901052300 |
| GA11 C | From 145000 | 2903087100 |
| GA11 C | From 255000 | 2901077900 |
| GA11 C | From 268500 | 2901077901 |
| GA11 PLUS | From 810000 | 2901196300 |
| GA11 VSD | From 700000 | 2202929450 |
| GA11 VSD+ | Â | 2202929450 |
| GA15 | Â | 1612386901 |
| GA15 | From 1993 | 2901000401 |
| GA15 | 1994 Up To 217791 | 2901000401 |
| GA15 | 1995 From 217792 | 2901034301 |
| GA15 | From 246349 | 2901034301 |
| GA15 C | From 255000 | 2901077900 |
| GA15 C | From 268500 | 2901077901 |
| GA15 PLUS | From 810000 | 2901196300 |
| GA15 VSD | From 700000 | 2202929450 |
| GA15 VSD+ | Â | 2202929450 |
| GA18 | Â | 1612386901 |
| GA18 | From 1993 | 2901000401 |
| GA18 | 1994 Up To 217791 | 2901000401 |
| GA18 | 1995 From 217792 | 2901034301 |
| GA18 | From 246349 | 2901034301 |
| GA18 C | From 255000 | 2901077900 |
| GA18 C | From 268500 | 2901077901 |
| GA18 VSD | Â | 2901077901 |
| GA18 PLUS | From 810000 | 2901196300 |
| GA22 | Â | 1612386901 |
| GA22 | From 1993 | 2901000401 |
| GA22 | 1994 Up To 217791 | 2901000401 |
| GA22 | 1995 From 217792 | 2901034301 |
| GA22 | From 246349 | 2901034301 |
| GA22 C | From 255000 | 2901077900 |
| GA22 C | From 268500 | 2901077901 |
| GA22 PLUS | From 268500 | 2901077901 |
| GA22 PLUS | From 810000 | 2901196300 |
| GA22 VSD | 297500-420963 | 2901077901 |
| GA26 PLUS | From 810000 | 2901196300 |
| GA30 | From 1994 | 2901021301 |
| GA30 | 1994 Up To 315329 | 2901021301 |
| GA30 | From 315330 | 2901021301 |
| GA30 | 1998 From 360000 | 2901056602 |
| GA30 | From 810000 | 2901196300 |
| GA30 C | From 255000 | 2901077900 |
| GA30 C | From 268500 | 2901077901 |
| GA30 PLUS | From 507438 | 2901162600 |
| GA30 PLUS | 2006 From 591000 | 2901164300 |
| GA30 VSD | Â | 2901056602 |
| GA37 | Â | 2901006101 |
| GA37 | From 1994 | 2901021301 |
| GA37 | 1994 Up To 315329 | 2901021301 |
| GA37 | From 315330 | 2901021301 |
| GA37 | 1998 From 360000 | 2901056602 |
| GA37 | 2006 From 591000 | 2901164300 |
| GA37 – 7.5 Bar | Â | 2901056602 |
| GA37 – 10 Bar | Â | 2901138900 |
| GA37 – 13 Bar | Â | 2901056602 |
| GA37 PLUS | From 507438 | 2901162600 |
| GA37 VSD | Â | 2901056602 |
| GA37 VSD | From 572446 | 2901162600 |
| GA45 | Â | 2903101001 |
| GA45 | From 1994 | 2901021301 |
| GA45 | From 1995 | 2903101001 |
| GA45 | 1994 Up To 315329 | 2901021301 |
| GA45 | From 315330 | 2901021301 |
| GA45 | 1998 From 360000 | 2901056602 |
| GA45 | 2006 From 591000 | 2901164300 |
| GA45 – 7.5 Bar | Â | 2901056602 |
| GA45 – 10 Bar | Â | 2901138900 |
| GA45 – 13 Bar | Â | 2901056602 |
| GA45 PLUS | From 507438 | 2901162600 |
| GA45 VSD | FRom 572446 | 2901162600 |
| GA50 | 1998 From 350000 | 2901056602 |
| GA50 VSD | Â | 2901056602 |
| GA55 | Â | 2903101001 |
| GA55 | From 1995 | 2903101001 |
| GA55 | 1996 From 460001 | 2901043200 |
| GA55 | From 2000 | 2901085800 |
| GA55 | From 507438 | 2901162600 |
| GA55 C | Â | 2901043200 |
| GA55 C | From 470999 | 2901085800 |
| GA55 C | From 470999 | 1613984100 |
| GA55 PLUS | From 2005 | 2901056622 |
| GA55 VSD | From 572446 | 2901162600 |
| GA75 | Â | 2903101001 |
| GA75 | From 1995 | 2903101001 |
| GA75 | 1996 From 460001 | 2901043200 |
| GA75 | From 2000 | 2901085800 |
| GA75 | From 471000 | 2901085800 |
| GA75 | From 507438 | 2901162610 |
| GA75 C | From 474000 | 2901085800 |
| GA75 PLUS | From 2005 | 2901056622 |
| GA75 VSD | Â | 2901085800 |
| GA90 | Â | 1614642399 |
| GA90 | 1999 From 056813 | 2906056400 |
| GA90 PLUS | From 2005 | 2901056622 |
| GA90 | From 2006 | 2906075100 |
| GA90 – 5.2-5.5 Bar | From 2008 | 2906095600 |
| GA90 – 10-14 Bar | From 2008 | 2906095400 |
| GA90 C | Â | 2901043200 |
| GA90 C | From 474000 | 2901085800 |
| GA90 VSD | Â | 2901056622 |
| GA100 | Â | 2901000300 |
| GA110 | Â | 1614642399 |
| GA110 | 1999 From 056813 | 2906056400 |
| GA110 | From 2006 | 2906075100 |
| GA110 PLUSÂ 10-14 Bar | From 2008 | 2906095400 |
| GA111 up to 122 | Â | 1612386901 |
| GA132 | Â | 1614642399 |
| GA132 | 1999 From 056813 | 2906056500 |
| GA132 | From 2006 | 2906075200 |
| GA132 – 5.2-5.5 Bar | From 2008 | 2906095600 |
| GA132 – 10-14 Bar | From 2008 | 2906095400 |
| GA160 | Â | 1614642399 |
| GA160 | 1999 From 056813 | 2906056500 |
| GA160 | From 2006 | 2906075200 |
| GA160Â – 5.2-5.5 Bar | From 2008 | 2906095600 |
| GA160Â – 10-14 Bar | From 2008 | 2906095400 |
| GA180 VSD | Â | 1614905699 |
| GA180 VSD | From 2006 | 2906075200 |
| GA200 | Â | 1614704899 |
| GA200 | From 1999 | 1614905699 |
| GA200 | From 2000 | 2906058800 |
| GA200 | From 2006 | 2906075300 |
| GA200 | From 2008 | 1621938699 |
| GA230 | Â | 1614532900 |
| GA237 | Â | 1614532900 |
| GA250 | Â | 1614704899 |
| GA250 | Â | 2906058800 |
| GA315 | Â | 1614704899 |
| GA315 | From 2000 | 2906058800 |
| GA315 | From 2006 | 2906075300 |
| GA315 VSD | Â | 2906058800 |
| GA315 VSD | From 2006 | 2906075300 |
| GA345 | Â | 1202834300 |
| GA355 | Â | 1202834300 |
| GA375 | Â | 1202834300 |
| GA450 | From 2006 | 2906075300 |
| GA507 up to 510 | Â | 2901007800 |
| GA607 upto 710 | Â | 2901008500 |
| GA807 up to 1110 | Â | 2906002000 |
| GAH 115 | Â | 2901000300 |
| GAH 118 | Â | 2901000300 |
| GAH 122 | Â | 2901000300 |
| GAU15 up to 40 | Â | 2901000300 |
| GAU307 up to 509 | Â | 2901007800 |
| GAU607 up to 709 | Â | 2901008500 |
| GAU807 up to 1409 | Â | 2906002000 |
| GR110 up to 200 | Â | 2906063800 |
| GR110 up to 200 | From 085972 | 1621938799 |
| GR620 | Â | 2901007800 |
| GR1120 | Â | 2906002000 |
| GX2 | Â | 2903062301 |
| GX3 | Â | 2903062301 |
| GX4 | Â | 2903062301 |
| GX5 | Â | 2903087100 |
| GX5 | New | 2903062301 |
| GX7 | Â | 2903087100 |
| GX7 | Up to 619999 | 2903087100 |
| GX7 | From 620000 | 2903087100 |
| GX11 | Â | 2903087100 |
| GX11 | Up to 619999 | 2903087100 |
| GX11 | From 620000 | 2903087100 |
| GX15 | Â | 2903035101 |
| GX18 | Â | 2903035101 |
| GX22 | Â | 2903035101 |
| Model | Air Filter |
|---|---|
| ZA4 | 1630040699 |
| ZA5 | 1630040699 |
| ZA6 | 1630040699 |
| ZR4 | 1630040699 |
| ZR5 | 1630040699 |
| ZR6 | 1630040699 |
| ZR75 | 1619279990 |
| ZR90 | 1619279990 |
| ZR110 | 1630040699 |
| ZR132 | 1630040699 |
| ZR145 | 1630040699 |
| ZR300 | 1630040699 |
| ZR315 | 1630040699 |
| ZR355 | 1630040699 |
| ZR400 | 1630040699 |
| ZR425 | 1630040699 |
| ZT4 | 1630040699 |
| ZT18 | 1613740800 |
| ZT22 | 1613740800 |
| ZT30 | 1613740800 |
| ZT37 | 1613740800 |
| ZT75 | 1619279990 |
| ZT90 | 1619279990 |
If Compressor Has Spin-On Type Oil Filter, Replacement Part # is 1613610590
| Model | Oil Filter |
|---|---|
| ZA3 | 2910001500 |
| ZA4 | 2910001500* |
| ZA4 | 1613610590 |
| ZA6 | 1613610590 |
| ZR3 | 2910001500 |
| ZR4 | 2910001500* |
| ZR4 | 1613610590 |
| ZR6 | 1613610590 |
| ZT3 | 2910001500 |
| ZT4 | 2910001500* |
| ZT4 | 1613610590 |
| Model | Air Filter |
|---|---|
| XA 60 | 1619284700 |
| XA 65 | 1619284700 |
| XA 70 | 1619284700 |
| XA 75 | 1619284700 |
| XA 80 | 1619284700 |
| XA 85 | 1619284700 |
| XA 90 | 1619284700 |
| XA 120 | 1619279800 |
| XA 125 | 1619279800 |
| XA 125 D | 1619279990 |
| XA 160 | 1619279990 |
| XA 175 | 1619279800 |
| XA 175 D | 1619279990 |
| XA 210 | 1619279800 |
| XA 210 D | 1619279800 |
| XA 250 | 1619279800 |
| XA 350 | 1619279800 |
| XA 350 D | 1619279800 |
| XAS 36 – From 2003 | 2914930200 |
| XAS 37 | 2903740700 |
| XAS 37 K | 2903740700 |
| XAS 46 | 2903740700 |
| XAS 46 D | 2903740700 |
| XAS 47 | 2903740700 |
| XAS 47 K | 2903740700 |
| XAS 55 D | 1619284700 |
| XAS 56 | 2903740700 |
| XAS 57 | 2903740700 |
| XAS 60 | 1619284700 |
| XAS 65 | 1619284700 |
| XAS 66 | 1613740800 |
| XAS 66 D | 2903740700 |
| XAS 67 | 1613740800 |
| XAS 75* | 1619284700 |
| XAS 75 D* | 1619284700 |
| XAS 75 D* | 1619532700 |
| XAS 75 DD | 1619284700 |
| XAS 76 | 2903740700 |
| XAS 80 | 1619284700 |
| XAS 80 D | 1619284700 |
| XAS 85* | 1619284700 |
| XAS 85 D | 1619284700 |
| XAS 90* | 1619284700 |
| XAS 90 D | 1619284700 |
| XAS 90 DD* | 1619284700 |
| XAS 90 DD* | 1619532700 |
| XAS 96 | 1613800400 |
| XAS 97 | 1613800400 |
| XAS 120 | 1619279800 |
| XAS 125 | 1619279800 |
| XAS 125 D | 1619279800 |
| XAS 136 | 1613800400 |
| XAS 146 | 1613800400 |
| XAS 160 | 1619279990 |
| XAS 175 | 1619279990 |
| XAS 175 D | 1619279990 |
| XAS 185* | 1310033926 |
| XAS 185* | 1310034381 |
| XAS 186 | 1613800400 |
| XAS 210 | 1619279800 |
| XAS 210 D | 1619279800 |
| XAS 230 | 1619279990 |
| XAS 280 | 1619279800 |
| XAS 350 | 1619279800 |
| XAS 350 D* | 1619279800 |
| XAS 350 D* | 1619554500 |
| XAS 366 CD* | 2914507700 |
| XAS 366 CD* | 2914501800 |
| XAS 426 MD* | 2914507700 |
| XAS 426 MD* | 2914501800 |
| XAS 430* | 1619279800 |
| XAS 430* | 1619554500 |
| XAS 430 D* | 1619279800 |
| XAS 430 D* | 1619554500 |
| XAS 495 MD* | 1619279990 |
| XAS 495 MD* | 2900052500 |
| Model | Oil Filter |
|---|---|
| XA 30 | 1613610590 |
| XA 35 | 1613610590 |
| XA 40 | 1613610590 |
| XA 40 D | 1613610590 |
| XA 45 | 1613610590 |
| XA 50 | 1613610590 |
| XA 50 D | 1613610590 |
| XA 55 | 1613610590 |
| XA 60 | 1613610590 |
| XA 65 | 1613610590 |
| XA 70 | 1613610590 |
| XA 75 | 1613610590 |
| XA 80 | 1613610590 |
| XA 85 | 1613610590 |
| XA 90 | 1613610590 |
| XA 120 | 1613610590 |
| XA 125 | 1613610590 |
| XA 125 D | 1613610590 |
| XA 160 | 1613610590 |
| XA 175 | 1613610590 |
| XA 175 D | 1613610590 |
| XA 210 | 1613610590 |
| XA 210 D | 1613610590 |
| XA 250 | 1613610590 |
| XA 350 | 1613610590 |
| XA 350 D | 1613610590 |
| XAS 25 | 1613610590 |
| XAS 26 | 1613610590 |
| XAS 30 | 1613610590 |
| XAS 32 | 1613610590 |
| XAS 35 | 1613610590 |
| XAS 36 | 1613610590 |
| XAS 36 – From 2003 | 1613610590 |
| XAS 37 | 1613610590 |
| XAS 37 K | 1613610590 |
| XAS 40 | 1613610590 |
| XAS 40 D | 1613610590 |
| XAS 45 | 1613610590 |
| XAS 46 | 1613610590 |
| XAS 46 D | 2914805800 |
| XAS 47 | 1613610590 |
| XAS 47 K | 1613610590 |
| XAS 50 | 1613610590 |
| XAS 50 D | 1613610590 |
| XAS 55 | 1613610590 |
| XAS 55 D | 1613610590 |
| XAS 56 | 1613610590 |
| XAS 57 | 1613610590 |
| XAS 60 | 1613610590 |
| XAS 65 | 1613610590 |
| XAS 66 | 1613610590 |
| XAS 66 D | 2914805800 |
| XAS 67 | 1613610590 |
| XAS 75* | 1613610590 |
| XAS 75 D | 1613610590 |
| XAS 75 DD | 1613610590 |
| XAS 76 | 1613610590 |
| XAS 80 | 1613610590 |
| XAS 80 D | 1613610590 |
| XAS 85* | 1613610590 |
| XAS 85 D | 1613610590 |
| XAS 90* | 1613610590 |
| XAS 90 D | 1613610590 |
| XAS 90 DD | 1613610590 |
| XAS 96 | 1613610590 |
| XAS 97 | 1613610590 |
| XAS 120 | 1613610590 |
| XAS 125 | 1613610590 |
| XAS 125 D | 1613610590 |
| XAS 136 | 1613610590 |
| XAS 146 | 1613610590 |
| XAS 160 | 1613610590 |
| XAS 175 | 1613610590 |
| XAS 175 D | 1613610590 |
| XAS 185* | 1613610590 |
| XAS 186 | 1613610590 |
| XAS 210 | 1613610590 |
| XAS 210 D | 1613610590 |
| XAS 230 | 1613610590 |
| XAS 280 | 1613610590 |
| XAS 350 | 1613610590 |
| XAS 350 D | 1613610590 |
| XAS 366 CD | 1613610590 |
| XAS 426 MD | 1613610590 |
| XAS 430 | 1613610590 |
| XAS 430 D | 1613610590 |
| XAS 495 MD | 1613610590 |
| Model | Separator |
|---|---|
| XA 30 | 2911001200 |
| XA 40 | 2911001300 |
| XA 40 D | 2911001300 |
| XA 50 | 2911001300 |
| XA 50 D | 2911001300 |
| XA 60 | 2911001300 |
| XA 75 | 2911001500 |
| XA 80 | 2901007800 |
| XA 85 | 2911001500 |
| XA 90 | 2911001500 |
| XA 120 | 2901008500 |
| XA 160 | 2901008500 |
| XA 210 | 2911002100 |
| XA 210 D | 2911002100 |
| XA 250 | 2901008500 |
| XA 350 D | 2252631399 |
| XAS 25 | 2911004000 |
| XAS 26 | 2911004000 |
| XAS 30 | 2911001200 |
| XAS 32 | 2911004000 |
| XAS 36 | 2911004000 |
| XAS 36 – From 2003 | 2911010500 |
| XAS 37 | 2911006800 |
| XAS 37 K | 2911010500 |
| XAS 40 | 2911001300 |
| XAS 40 D | 2911001300 |
| XAS 46 | 2911006800 |
| XAS 46 D | 2911006800 |
| XAS 47 | 2911006800 |
| XAS 47 K | 2911010500 |
| XAS 50 | 2911001300 |
| XAS 50 D | 2911001300 |
| XAS 56 | 2911006800 |
| XAS 57 | 2911006800 |
| XAS 60 | 2911001300 |
| XAS 66 | 2911006800 |
| XAS 66 D | 2911006800 |
| XAS 67 | 2911006800 |
| XAS 75* | 2901000300 |
| XAS 75* | 2911001500 |
| XAS 75 D | 2911001500 |
| XAS 76 | 2911006800 |
| XAS 80 D | 2901007800 |
| XAS 85* | 2901000300 |
| XAS 85* | 2911001500 |
| XAS 85 D | 2911001500 |
| XAS 90* | 2901000300 |
| XAS 90* | 2911001500 |
| XAS 90 D | 2911001500 |
| XAS 90 DD | 2911001500 |
| XAS 96 | 2911006800 |
| XAS 97 | 2911006800 |
| XAS 120 | 2901008500 |
| XAS 160 | 2901008500 |
| XAS 185* | 2911006800 |
| XAS 185* | 2901000300 |
| XAS 210 | 2911002100 |
| XAS 210 D | 2911002100 |
| XAS 350 D | 2252631399 |
| XAS 366 CD | 2911011203 |
| XAS 426 MD | 2911011702 |
| XAS 430 D | 2252631399 |
Comprehensive Maintenance Kits for Atlas Copco Equipment
Avoid Unplanned Downtime
Forgetting to order a single component can leave a service intervention incomplete, leading to follow-up maintenance, unexpected downtime, and unnecessary labor costs. All-in-one service kits designed for Atlas Copco equipment bundle every required replacement part into a single package, ensuring your maintenance runs smoothly from start to finish.
Why Quality Replacement Parts Matter
Low-grade generic air filters lack the exact specifications required for your compressor or vacuum pump, placing your equipment at risk. Subpar components often suffer from shorter lifespans, increased energy consumption, and reduced performance. Choosing high-specification replacement parts ensures optimal air quality, efficiency, and system protection.
Simplify Parts Administration
Streamline procurement with convenient, pre-packaged maintenance kits. Instead of researching and selecting individual components for every service interval, ordering is reduced to a single item. This minimizes administrative overhead, simplifies inventory tracking, and makes ongoing maintenance effortless.
Maximize Compressor and Vacuum Pump Lifespan
Dust and dirt contamination can degrade rotors and cause severe performance loss. Precision replacement filter elements with high filtration efficiency safeguard your machinery against wear. Built to withstand high operating pressures and extreme temperatures, these heavy-duty filters provide superior dirt-holding capacity to keep your installation running reliably.
Avoid Inferior Universal Filters
Generic one-size-fits-all filters often make performance concessions to accommodate multiple machine brands, leading to pressure drops, higher energy bills, or sudden breakdowns. High-grade replacement filters engineered specifically to match equipment requirements preserve operational integrity and keep running costs low.
Keep Getting the Most Out of Your Equipment
High-grade replacement filters and air-oil separators deliver ideal operating efficiency and extend equipment service life while keeping maintenance straightforward and cost-effective.
*Disclaimer: Product names, logos, brands, and trademarks referenced herein are the property of their respective trademark holders. Reference to Atlas Copco equipment is solely for product compatibility identification. Items offered are high-quality compatible replacement parts and are not manufactured by or affiliated with the original equipment manufacturer.
High-Performance Replacement Parts for Atlas Copco Equipment
Engineered to Factory Specifications
High-grade replacement parts designed for Atlas Copco machinery are engineered to match exact operational tolerances and performance requirements. Using precision-built components guards against premature wear, preserves output efficiency, and protects your capital investment without paying premium OEM markups.
The Importance of Quality-Tested Components
While many compressor operators rely on independent suppliers to reduce maintenance overhead, not all third-party components deliver the same standard of protection. Subpar, low-cost filters and lubricants can cause hidden internal wear, drop system efficiency, and compromise process air purity—leading to higher long-term operating costs. Selecting premium, fully compatible replacement parts ensures your equipment remains protected while keeping service budgets under control.
Maintain Peak Efficiency Throughout System Lifespan
Keeping your compressor running at design performance requires parts built to handle demanding industrial conditions. High-specification replacement filters and separators preserve operational airflow, limit pressure drop, and maintain air output quality from routine service through to full equipment retirement.
Your Source for Compatible Atlas Copco Compressor Parts
Compressor Now provides top-tier aftermarket replacement parts engineered specifically for Atlas Copco equipment. We carry a full range of compatible air filters, oil filters, air-oil separators, and maintenance components designed to keep your systems operating reliably.
*Disclaimer: Compressor Now is an independent supplier of aftermarket compressor parts and is not affiliated with or authorized by Atlas Copco. All original equipment manufacturer (OEM) names, model numbers, and part descriptions are used strictly for compatibility identification. Replacement parts supplied are high-quality non-OEM components.
Not Sure What You Need, We Will Help You Find The Right Atlas Copco Service Kit
