Quincy Parts, Filters and Lubricants

CompressorNow.com has the Quincy oil filters, air filters, separators, lubricants and parts. We offer fast service and do the digging for your compressor & dryer service parts and service kits. We make both Quincy OEM and Quincy OEM equivalent parts available with most shipping within 24 hours.

Quincy Parts Quick

Need a part for your Quincy machine quick, we have you covered. Finally a responsive and reliable source to get the Air Compressor filters, lubricants and parts you need. Ask about our hassle free maintenance program. We send you out the right parts at the right time based on your machine hourly usage. No contract, no worry. You get the correct parts at the correct time to keep downtime to a bare minimum. Parts listed are as a courtesy reference and are not a warranty or guarantee of proper parts for any particular machine. Consult your parts manual if in doubt.

Search All by Table or Column. Tables are by Quincy Model below.

ModelPartSpecificsPart Number
QGV 150/200Oil Filter ElementSold by Case Only (12)142136CS
QR 5120Quincip ISO 68112542Q068
QGV 150/200Air Filter Element146397-12
QR 5120Quincip ISO 100112543Q100
QGV 150/200 Oil Separator 150 (3 Req) 200 (4 Req)2013800404
QP 5/7.5Air Filter110377E100
QGV 150/200Vent Filter TopSiemens Master Drive/G120144995-332
QP 5/7.5Oil FilterSix Pack110814-001
QGV 150/200Temperature Probe2014000023
QP 5/7.5BeltsQP 5110258B060
QGV 150/200Temperature Switch230F122880-232
QP 5/7.5BeltsQP 7.5110258B061
QGV 150/200Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QP 5/7.5Valve Kit QT5QP 5KQT5A
QGV 150/200Min. Pressure Check Valve146342-050
QP 5/7.5Valve Kit QT7.5QP 7.5KQT75HA
QGV 150/200Transducer145072-1
QP 5/7.5Ring KitQP 5 LP111199
QGV 150/200Drive panel Element144995-332
QP 5/7.5Ring KitQP 5 HP111200
QGV 150/200Line Filter Kit129732-051
QP 5/7.5Ring KitQP 7.5 LP114209
QGV 150/200Moisture Separator KitIncludes Gasket124827-052
QP 5/7.5Ring KitQP 7.5 HP114210
QGV 150/200Air Regulator Kit23543-050
QP 5/7.5Vibration Pads800# per pad, 3,200 for the set7802-1set
QMB 10-30Oil Filter Sold by Case Only (12)128598CS
QP 5/7.5Vibration Pads1,200# per pad, 4,800 for the set7803-1set
QMB 10-30Air Filter128849E362
QP 5/7.5Quincip DQuart- REQUIRES 2115468Q
QMB 10-30Oil Separator 2013402030
QP 5/7.5QP 5 Minor KitAir Filter/Quincip D2022103400
QMB 10-30Temp ProbeMicroprocessor-High Vibration143754
QP 5/7.5QP 7.5 Minor KitAir Filter/Quincip D2022103400
QSI 220/245 Air filterJan 93-After23458-4
QMB 10-30Temperature SwitchGauge-225F122880s222
QP 10/15Air Filter110377E100
QSI 220/245 Oil separator Jan 93-After2013402021
QMB 10-30Shaft Seal KitSlinger, Shaft Seal & Wear Ring129216
QP 10/15Oil Filter110814-001
QSI 220/245 Temp. Switch 225F- 2 required122880-222
QMB 10-30Line Filter Kit(includes bowl seal, filter element, gasket)129732-051
QP 10/15BeltsQP 10110258B082
QSI 220/245 Temp. Switch 250F-2 required122880-252
QMB 10-30Min. Pressure Check Valve128813-050
QP 10/15BeltsQP 15110258B098
QSI 220/245 Temp. Switch240F122880-242
QMB 10-30Transducer142133
QP 10/15Valve Kit QT5QP 10KQT10H
QSI 220/245 Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QMB 10-30Differential Pilot Valve Kit(includes diaphragm assembly & seat)146175-100
QP 10/15Valve Kit QT7.5QP 15KQT15B
QSI 220/245 Line Filter KitPilot Valve129731-050
QMB 10-30Moisture Sep. KitIncludes Gasket124827-052
QP 10/15Ring KitQP10 LP116176
QSI 220/245 Line Filter KitUnload Solenoid143316-050
QMA 50/60Oil Filter Filters Sold by Case Only128381-050CS
QP 10/15Ring KitQP10 HP116177
QSI 220/245 Min Pressure Check Valve Kit128691-051
QMA 50/60Air FilterHeavy Duty23458-1
QP 10/15Ring KitQP15 LP8161
QSI 220/245 Min Pressure Check Valve Kit128691-054
QMA 50/60Oil Separator 2013402028
QP 10/15Ring KitQP15 HP8166
QSI 220/245 Thermostatic Valve Kit124973-060
QMA 50/60Temperature Switch225F122880S222
QP 10/15Vibration Pads800# per pad, 3,200 for the set7802-1set
QSI 220/245 Thermostatic Valve Kit124973-069 / 124973-070 / 124973-071
QMA 50/60Shaft Seal KitSlinger, Shaft Seal & Wear Ring140517
QP 10/15Vibration Pads1,200# per pad, 4,800 for the set7803-1set
QSI 220/245 Moisture Separator KitIncludes Gasket124827-052
QMA 50/60Line Filter Kit(includes bowl seal, filter element, gasket)129731-050
QP 10/15Quincip DQP-10 reqs 4 with the filter, QP-15 reqs 5 with the filter115468Q
QSI 220/245 Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QMA 50/60Min. Pressure Check ValveWye Delta Units128691-051
QP 10/15QP 10 Minor KitAir Filter/Quincip D2022103500
QSI 235Oil filter 1974-July 198222722-1
QMA 50/60Differential Pilot Valve KitDiaphragm Assembly/Seat20775
QP 10/15QP 15 Minor KitAir Filter/Quincip D2022103600
QSI 235Oil filter Heavy Duty23458-4
QMA 50/60Moisture Sep. KitIncludes Gasket124827-052
QSI 235Oil filter July 1982-June 1989124331-050
QMA 75Oil Filter Filters Sold by Case Only142136CS
QSI 235Oil filter June 1989-After142136cs
QMA 75Air FilterHeavy Duty23458-4
QSI 235 Air filter1974-July 198223458-1
QMA 75Oil Separator 2013402026
QSI 235 Air filterJuly 1982-Jan 1987125042-001
QMA 75Temperature SwitchRequires 2122880S222
QSI 235 Air filterJan 1987-After127058E350
QMA 75Shaft Seal KitSlinger, Shaft Seal & Wear Ring140517
QSI 235Oil separator July 1982-After2013402008
QMA 75Line Filter Kit(includes bowl seal, filter element, gasket)129731-050
QSI 235Line Filter Kit125049-001
QMA 75Min. Pressure Check Valve(wye-delta units)128691-052
QSI 250/300Oil filter Sold by Case Only (6) After 1/99142136cs
QMA 75Differential Pilot Valve KitDiaphragm Assembly/Seat20775
QSI 250/300 Air filterJan 93-After23458-4
QMA 75Moisture Sep. KitIncludes Gasket124827-052
QSI 250/300Oil separator 1/93-11/982013402021
QMA 100/125/150Oil Filter Sold by Case Only (12)128381-050CS
QSI 250/300Temp. Switch x 2225F PLC- 2 required122880-222
QMA 100/125/150Air Filter23458-5
QSI 250/300Temp. Switch240F Power Sync122880-242
QMA 100/125/150Oil Separator 2013402026
QSI 250/300Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QMA 100/125/150Temperature Switch122880S222
QSI 250/300Line Filter KitPilot Valve129731-050
QMA 100/125/150Temperature Switch122880-222
QSI 250/300Line Filter KitUnload Solenoid143316-050
QMA 100/125/150Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QSI 250/300Min Pressure Check Valve Kit128691-051
QMA 100/125/150Min. Pressure Check Valve146342-050
QSI 250/300Thermostatic Valve Kit124973-060
QMA 100/125/150Kit-Diff Pilot ValveDiaphragm Assembly/Seat20775
QSI 250/300Moisture Separator KitIncludes Gasket124827-052
QMA 100/125/150Line Filter Kit(includes bowl seal, filter element, gasket)129731-050
QSI 250/300Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QMA 100/125/150Moisture Separator Kit(includes gasket)124827-052
QSI 335/370Oil filter Sold by Case Only (6)142136CS
QMA 100/125/150Timer 15 Minute122862-900
QSI 335/370Air filterJan 1993-After23458-4
QMA 100/125/150Timer-15 SecondsWye-Delta Only122862-15
QSI 335/370Oil separator Jan 1993-After2013402009
QMA 100/125/150RelayRequires 2125706-005
QSI 335/370Temp. Switch x 2225F PLC- 2 required122880-222
QMA 100/125/150O-Ring Viton22749-123
QSI 335/370Temp. Switch x 2250F PLC-2 required122880-252
QMA 100/125/150Resevoir Top Plate128341
QSI 335/370Temp. Switch240F Power Sync122880-242
QMA 100/125/150Moisture Separator KitIncludes Gasket124827-051
QSI 335/370Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSLP 10/15/20 Oil Filter Sold by Case Only (6)128381-050CS
QSI 335/370Line Filter KitPilot Valve129731-050
QSLP 10/15/20Air FilterHeavy Duty125420E300
QSI 335/370Line Filter KitUnload Solenoid143316-050
QSLP 10/15/20 Oil Separator Primary127138-003
QSI 335/370Min Pressure Check Valve Kit128691-052
QSLP 10/15/20Oil SeparatorSecondary2013401998
QSI 335/370Min Pressure Check Valve Kit128691-054
QSLP 10/15/20Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSI 335/370Thermostatic Valve Kit124973-060
QSLP 30/60 Oil Filter Sold by Case Only (6)142136CS
QSI 335/370Thermostatic Valve Kit124973-069
QSLP 30/60Air Filter30HP23458-4
QSI 335/370Moisture Separator KitIncludes Gasket124827-052
QSLP 30/60Air Filter60HP23458-2
QSI 335/370Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QSLP 30/60Oil Separator 2013402018
QSI 350Oil filter 1974-198322722-1
QSLP 30/60Temperature SwitchPLC-Requires 2122880-232
QSI 350Oil filter After June 1983124331-050
QSLP 30/60Temperature SwitchPower Sync122880-242
QSI 350Oil filter 1990 and after142136cs
QSLP 30/60Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSI 350Air filter1974-June 198323458-4
QSLP 30/60Line Filter Kit(includes bowl seal, filter element, gasket)129731-050
QSI 350Air filter1987-After127058E350
QSLP 30/60Line Filter Kit(includes bowl seal, filter element, gasket)143316-050
QSI 350Oil separator 1974-19832013402042
QSLP 30/60Min. Pressure Check Valve128691-058
QSI 350Oil separator June 1983-19902013402009
QSLP 30/60Thermal Valve Kit125657-055
QSI 350Oil separator After 19902013402008
QSLP 30/60Moisture Sep. KitIncludes Gasket124827-052
QSI 350Oil Seal22722-2
QSLP 100Oil Filter Sold by Case Only (6)142136CS
QSI 350Secondary separator2013402003
QSLP 100Air Filter23458-5
QSI 440/500Oil filter Sold by Case Only (6) 1/99-Current142136CS
QSLP 100 Oil Separator 2013402018
QSI 440/500Air filter1993-March 199823458-2
QSLP 100Temperature SwitchRequires 2122880-232
QSI 440/500Air filter3/1/1998-200923458-5
QSLP 100Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSI 440/500Air filter200923458-20
QSLP 100Min. Pressure Check Valve128691-058
QSI 440/500Oil separator 1993-20092013402009
QSLP 100Kit-Diff Pilot ValveDiaphragm Assembly/Seat146175-100
QSI 440/500Oil separator Nov 03-After2013402020
QSLP 100Line Filter Kit(includes bowl seal, filter element, gasket)129731-050
QSI 440/500Temp. Switch x 2225F PLC- 2 required122880-222
QSLP 100Line Filter Kit(includes bowl seal, filter element, gasket)143316-050
QSI 440/500Temp. Switch x 2250F PLC-2 required122880-252
QSLP 100Moisture Separator KitIncludes Gasket124827-052
QSI 440/500Temp. Switch240F Power Sync122880-242
QSLP 125Oil Filter Sold by Case Only (6)142136CS
QSI 440/500Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QSLP 125Air Filter Requires 223458-5
QSI 440/500Line Filter KitPilot Valve129731-050
QSLP 125 Oil Separator 2013402019
QSI 440/500Line Filter KitUnload Solenoid143316-050
QSLP 125Temperature Switch122880-232
QSI 440/500Min Pressure Check Valve Kit128691-052
QSLP 125Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QSI 440/500Min Pressure Check Valve Kit128691-054
QSLP 125Min. Pressure Check Valve142566-050
QSI 440/500Thermostatic Valve Kit124973-065
QSLP 125Kit-Diff Pilot ValveDiaphragm Assembly/Seat20775
QSI 440/500Thermostatic Valve Kit124973-067
QSLP 125Line Filter Kit129731-050
QSI 440/500Moisture Separator KitIncludes Gasket124827-052
QSLP 125Relay Flange Mounted Requires 2125706-005
QSI 440/500Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QSLP 125Thermostatic Valve Kit(includes element, gasket,seal)125657-067
QSI 490Oil filter 1974-198522722-1
QSLP 125Moisture Separator KitIncludes Gasket124827-052
QSI 490Oil filter After 1985125656-050
QSLP 150Oil Filter Sold by Case Only (6)142136CS
QSI 490Oil filter After 1989142136cs
QSLP 150Air FilterRequires 223458-5
QSI 490Air filter1974-8523458-3
QSLP 150 Oil Separator 2013402019
QSI 490Air filterAfter 1985125420E400
QSLP 150Temperature Switch230F122880-232
QSI 490Air filter12/1/1990-After127058E350
QSLP 150Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QSI 490Oil separator 2013402043
QSLP 150Min. Pressure Check Valve142566-050
QSI 490Oil separator Secondary2013402004
QSLP 150Kit-Diff Pilot Valve(includes diaphragm,20775
QSI 490Oil separator After 19852013402009
QSLP 150Line Filter Kitdiaphragm gaskets, seat gasket, seat disk, seat ring)129731-050
QSI 490Line Filter KitPilot Valve125049-001
QSLP 150Relay Flange Mounted Requires 2125706-005
QSI 540/600Oil filter Sold by Case Only (6) After Jan 99142136CS
QSLP 150Thermostatic Valve Kit(includes element, gasket, seal)125657-067
QSI 540/600Air filter10/10-Current23458-20
QSLP 150Moisture Separator KitIncludes Gasket124827-052
QSI 540/600Oil separator Oct 99-After124487-018
QSLP 200Oil Filter x 2Sold by Case Only (6)142136CS
QSI 540/600Temp. Switch x 2225F PLC-2 required122880-232
QSLP 200Air Filter (Heavy Duty)23458-7
QSI 540/600Temp. Switch240F Power Sync122880-242
QSLP 200 Oil Separator Primary2013402041
QSI 540/600Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QSLP 200 Oil Separator Secondary2013402002
QSI 540/600Line Filter KitPilot Valve129731-050
QSLP 200Temperature SwitchRequires 2122880-232
QSI 540/600Line Filter KitUnload Solenoid143316-050
QSLP 200Shaft Seal KitSlinger, Shaft Seal & Wear Ring141115
QSI 540/600Min Pressure Check Valve Kit128691-052
QSLP 200Min. Pressure Check Valve142566-050
QSI 540/600Thermostatic Valve Kit124973-067
QSLP 200Kit-Diff Pressure Regulator(includes diaphragm, gasket, seat gasket, seat disk, and seat ring)121904
QSI 540/600Moisture Separator KitIncludes Gasket124827-052
QSLP 200Line Filter Kit129731-050
QSI 540/600Diff Pilot Valve KitDiaphragm Assembly/Seat20775
QSLP 200Relay Flange Mounted Requires 2125706-005
QSI 675/750Oil Filter750 HP 3/98 to current142243cs
QSLP 200Thermostatic Valve Kit125657-067
QSI 675/750Oil filter x 2Sold by Case Only (6)142136CS
QSLP 200Moisture Separator KitIncludes Gasket124827-052
QSI 675/750Air filter750HP23458-5
QSVB 7.5-25 Oil Filter Sold by Case Only (12)128381-050CS
QSI 675/750Air filter23458-18
QSVB 7.5-25 Air Filter141469-052
QSI 675/750Oil separator 8/93-3/982013402044
QSVB 7.5-25 Fluid StrainerCase Only141100-050CS
QSI 675/750Oil separator 3/98-3/992013402046
QSVB 7.5-25 Temperature122880-252
QSI 675/750Oil separator March 99-After2013402010
QSVB 7.5-25 Belt Set7.5 hp128085-360
QSI 675/750Temp. Switch x 2225F PLC- 2 required122880-232
QSVB 7.5-25 Belt Set10 hp128085-363
QSI 675/750Temp. Switch240F Power Sync122880-242
QSVB 7.5-25 Belt Set15 hp128085-356
QSI 675/750Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QSVB 7.5-25 Belt Set20 hp128085-367
QSI 675/750Line Filter KitPilot Valve129731-050
QSVB 7.5-25 Belt Set25 hp128085-360
QSI 675/750Line Filter KitUnload Solenoid143316-050
QSVB 7.5-25 Timer-15 Minute122862-900
QSI 675/750Min Pressure Check Valve Kit128691-052
QSVB 7.5-25 Relay-Control2 Required125706-005
QSI 675/750Thermostatic Valve Kit124973-067
QSVB 7.5-25 Oil Separator 7.5-15 hp2013402032
QSI 675/750Moisture Separator KitIncludes Gasket124827-052
QSVB 7.5-25 Oil Separator20 & 25 hp2013402033
QSI 675/750Diff Pilot Valve KitDiaphragm Assembly/Seat20775
QSVB 7.5-25 Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSI 740Oil FilterJan 1974-Sept 198922722-1
QSVB 7.5-25 Inlet Valve Kit126865-050
QSI 740Oil FilterSept 89-March 98142136cs
QSVB 7.5-25 Thermostatic Valve7.5-15 hp128786-058
QSI 740 Air filter1974-198623458-4
QSVB 7.5-25 Thermostatic Valve20 & 25 hp128786-056
QSI 740 Air filterAfter 198623458-5
QSV 20/40Oil Filter Sold by Case Only (12)128381-050CS
QSI 740Oil separator Primary2013402044
QSV 20/40Inlet Filter ElementQSV 25hp141469-052
QSI 740Oil separator Secondary2013402005
QSV 20/40Inlet Filter ElementQSV-40hp127357E004
QSI 925/1000Oil filter x 2Sold by Case Only (6)142136CS
QSV 20/40Temperature250F122880-252
QSI 925/1000Oil filter x 21974-199522722-1
QSV 20/40Oil Separator 2013402031
QSI 925/1000 Air filter1000- jan 1974-8/8423458-3
QSV 20/40Shaft Seal Kit140517
QSI 925/1000 Air filter10/86-present23458-5
QSV 20/40Diff Pilot ValveDiaphragm Assembly/Seat146233-100
QSI 925/1000Oil separator Primary2013402045
QSVi 25/40Oil Filter Sold by Case Only (12)128381-050CS
QSI 925/1000Oil separator Primary2013402021
QSVi 25/40Inlet Filter Element25 hp141469-052
QSI 925/1000Oil separator Secondary2013402006
QSVi 25/40Inlet Filter Element40 hp127357E004
QSI 925/1000Temp. Switch x 2Standard Unit-2 required122880-232
QSVi 25/40Oil Separator 2013402034
QSI 925/1000Temp. Switch240F Power Sync122880-242
QSVi 25/40Shaft Seal Kit 40 HPSlinger, Shaft Seal & Wear Ring140517
QSI 925/1000Shaft Seal KitSlinger, Shaft Seal & Wear Ring141115
QSVi 25/40Shaft Seal Kit 25 HPSlinger, Shaft Seal & Wear Ring140209
QSI 925/1000Line Filter KitPilot Valve129731-050
QSVi 25/40Diff Pilot Valve146233-100
QSI 925/1000Line Filter KitUnload Solenoid143316-050
QSVi 50Oil Filter Sold by Case Only (12)128381-050CS
QSI 925/1000Min Pressure Check Valve Kit128691-052
QSVi 50Inlet Filter ElementRequires 2127357E005
QSI 925/1000Thermostatic Valve Kit(includes element, gasket & seal)22331-005
QSVi 50TemperatureRequires 2122880-252
QSI 925/1000Moisture Separator KitIncludes Gasket124827-052
QSVi 50Oil Separator 2013402035
QSI 925/1000Diff Pilot Valve Kit-Power $yncDiaphragm Assembly/Seat20775
QSVi 50Element StrainerSold by Case Only141100-050CS
QSI 925/1000Diff Pilot Valve Kit-Standard UnitDiaphragm Assembly/Seat121904
QSVi 50Thermostatic Valve128786-058
QSI 1175/1250Oil filter- 2 requiredSold by Case Only (6) 1991-Current142243CS
QSVi 75Oil Filter Sold by Case Only (12)142136CS
QSI 1175/1250Oil filter- 2 required1974-199122722-1
QSVi 75Inlet Filter ElementCall to Determine which Filter141469-052
QSI 1175/1250 Air filter1/74-8/8423458-3
QSVi 75Inlet Filter ElementCall to Determine which Filter127357E004
QSI 1175/1250 Air filter8/84-present23458-5
QSVi 75TemperatureRequires 2122880-252
QSI 1175/1250Oil separator Primary2013402046
QSVi 75Oil Separator 2013402036
QSI 1175/1250Oil separator Secondary2013402007
QSVi 75Transformer x 21.5 AMP128857-004
QSI 1175/1250Temp. Switch x 2Standard Unit- 2 required122880-232
QSVi 75Transformer x 24AMP128857-007
QSI 1175/1250Temp. Switch240F Power Sync122880-242
QSVi 75Fan Motor x 3128857-032
QSI 1175/1250Shaft Seal KitSlinger, Shaft Seal & Wear Ring141115
QSVi 75INCADESCANTAmber143144-01
QSI 1175/1250Line Filter KitPilot Valve129731-050
QSVi 75INCADESCANTRed143144-02
QSI 1175/1250Line Filter KitUnload Solenoid143316-050
QSVi 7515 Minute122862-900
QSI 1175/1250Min Pressure Check Valve Kit128691-053
QSVi 200Oil Filter x 2Sold by Case Only (6)142136CS
QSI 1175/1250Thermostatic Valve Kit22331-005
QSVi 200Air Filter Element23458-4
QSI 1175/1250Moisture Separator KitIncludes Gasket124827-052
QSVi 200Oil Separator Primary2013402038
QSI 1175/1250Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QSVi 200Oil Separator Secondary2013402039
QSI 1400/1500Oil filter- 2 requiredSold by Case Only (6) August 89-Current142243CS
QSVi 200Thermostatic Valve125657-060
QSI 1400/1500Oil filter- 2 required1500 1974 Early Element22722-1
QSVi 200Shaft Seal KitSlinger, Shaft Seal & Wear Ring141115
QSI 1400/1500 Air filter23458-9
QSVi 200Thermal Valve Element125657-057
QSI 1400/1500 Air filter1974-11/8623458-3
QSVi 200Thermal Valve Gasket125657-051
QSI 1400/1500 Air filter11/86-200923458-5
QSVi 200Thermal Valve Seal125657-052
QSI 1400/1500Oil separator Primary2013402046
QGB 7.5-15VOil Filter 146513-1
QSI 1400/1500Oil separator Secondary2013402007
QGB 7.5-15VAir Filter146515-1
QSI 1400/1500Temp. Switch x 2Standard Unit- 2 required122880-232
QGB 7.5-15VSeparator146514-1
QSI 1400/1500Temp. Switch240F Power Sync122880-242
QGB 30-60Oil Filter Sold by Case Only (12)142136CS
QSI 1400/1500Shaft Seal KitSlinger, Shaft Seal & Wear Ring141115
QGB 30-60Air Filter Element146397-08
QSI 1400/1500Line Filter KitPilot Valve129731-050
QGB 30-60 Oil Separator 2013800404
QSI 1400/1500Line Filter KitUnload Solenoid143316-050
QGB 30-60Shaft Seal Kit140209
QSI 1400/1500Min Pressure Check Valve Kit128691-053
QGB 30-60Thermal Valve KitElement, Gasket & Seal124973-060
QSI 1400/1500Thermostatic Valve KitElement, Gasket & Seal22331-005
QGB 30-60Min. Pressure Check Valve Kit128691-051
QSI 1400/1500Moisture Separator KitIncludes Gasket124827-052
QT54, QT5-QT 7.5Air FilterQT 5 & QT 7.5110377E100
QSI 1400/1500Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QT54, QT5-QT 7.5Air FilterQT 54112845-06
QSIi 220/245Oil FilterSold by Case Only (6)142136CS
QT54, QT5-QT 7.5BeltsQT54 and QT5110258B060
QSIi 220/245Air Filter146397-08
QT54, QT5-QT 7.5BeltsQT 7.5110258B061
QSIi 220/245Oil Separator 2013800404
QT54, QT5-QT 7.5Valve Kit QT54QT54 113047-001
QSIi 220/245Temp. Switch 122880-232
QT54, QT5-QT 7.5Valve Kit QT5QT 5114096-002
QSIi 220/245Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QT54, QT5-QT 7.5Valve Kit QT7.5QT 7.5114419-001
QSIi 220/245Min Pressure Check Valve Kit128691-051
QT54, QT5-QT 7.5Set of 4800# per pad, 3,200 for the set7802-1set
QSIi 220/245Thermostatic Valve Kit124973-060
QT54, QT5-QT 7.5Set of 41,200# per pad, 4,800 for the set7803-1set
QSIi 220/245Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QT54, QT5-QT 7.5Quincip D115468Q
QSIi 250/300Oil filter Sold by Case Only (6)142136CS
QT54, QT5-QT 7.5Quincip ISO 68112542Q068
QSIi 250/300Air Filter146397-08
QT54, QT5-QT 7.5Quincip ISO 100112543Q100
QSIi 250/300Oil Separator 2013800404
QT54, QT5-QT 7.5One Year Maintenance KitQT54114325-015
QSIi 250/300Temp. Switch 122880-232
QT54, QT5-QT 7.5One Year Maintenance KitQT5/7.5114325-008
QSIi 250/300Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QT 10-15Air FilterQt 15- Requires 2110377E100
QSIi 250/300Min Pressure Check Valve Kit128691-051
QT 10-15BeltsQT10110258B082
QSIi 250/300Thermostatic Valve Kit124973-060
QT 10-15BeltsQT 15110258B098
QSIi 250/300Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QT 10-15Valve Kit QT10 LPQT10 116162K1
QSIi 335/370Oil FilterSold by Case Only (6)142136CS
QT 10-15Valve Kit QT10 HPQT10116163K1
QSIi 335/370Air Filter146397-08
QT 10-15Valve Kit QT15 – LPQT 15 – 2 req112713M15
QSIi 335/370Oil separator 2013800404
QT 10-15Valve Kit Qt 15 – HPQT 15 – 2 req112714
QSIi 335/370Temp. Switch 122880-232
QT 10-15Set of 4800# per pad, 3,200 for the set7802-1set
QSIi 335/370Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QT 10-15Set of 41,200# per pad, 4,800 for the set7803-1set
QSIi 335/370Thermostatic Valve Kit125657-067
QT 10-15Quincip D115468Q
QSIi 335/370Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QT 10-15Quincip ISO 68112542Q068
QSIi 440/500Oil FilterSold by Case Only (6)142136CS
QT 10-15Quincip ISO 100112543Q100
QSIi 440/500Air Filter146397-10
QT 10-15One Year Maintenance KitQT 10114325-011
QSIi 440/500Oil separator 2013800404
QT 10-15One Year Maintenance KitQT 15114325-009
QSIi 440/500Temp. Switch 122880-232
QT 30Air FilterQT30-REQUIRES 2110377E100
QSIi 440/500Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QT 30Belts20 HP110258B116
QSIi 440/500Thermostatic Valve Kit125657-067
QT 30Belts25/30 HP 100psi110258B120
QSIi 440/500Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QT 30Set of 4800# per pad, 3,200 for the set7802-1set
QGV 20/25/30Oil Filter ElementSold by Case Only (12)128598CS
QT 30Set of 41,200# per pad, 4,800 for the set7803-1set
QGV 20/25/30Air Filter Element128849E362
QT 30Quincip D115468Q
QGV 20/25/30Oil Separator Element2012100079
QT 30Quincip ISO 68112542Q068
QGV 20/25/30Temp ProbeMicroprocessor2014000023
QT 30Quincip ISO 100112543Q100
QGV 20/25/30Temperature SwitchGauge 230F122880-232
QT 30One Year Maintenance KitQT 30114325-019
QGV 20/25/30Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QR 310/325Air Filter110377E100
QGV 20/25/30Line Filter Kit129732-051
QR 310/325Oil Filtersix pack110814-001
QGV 20/25/30Min. Pressure Check Valve147564K
QR 310/325BeltsQR 310110258B057
QGV 20/25/30Transducer145072-1
QR 310/325BeltsQR 325110258B068
QGV 20/25/30Differential Pilot Valve Kit146175-100
QR 310/325Head Kit QR 310QR 310K310A
QGV 20/25/30Transformer Fuse x 2Primary128857-011
QR 310/325Head Kit QR 325QR 325K325A
QGV 20/25/30Transformer Fuse Secondary128622-250
QR 310/325Set of 4800# per pad, 3,200 for the set7802-1set
QGV 40/50/60Oil Filter ElementSold by Case Only (12)142136CS
QR 310/325Set of 41,200# per pad, 4,800 for the set7803-1set
QGV 40/50/60Air Filter Element125420E200
QR 310/325Quincip ISO 68112542Q068
QGV 40/50/60Oil Separator Element Kit2012100079
QR 310/325Quincip ISO 100112543Q100
QGV 40/50/60Vent Filter Siemens G120144995-332
QR 340/350/370Air Filter110377E200
QGV 40/50/60Vent Filter TopSiemens Master Drive144995-152
QR 340/350/370Oil Filter6 pack110814-001
QGV 40/50/60Vent Filter BottomSiemens Master Drive144995-072
QR 340/350/370BeltsQR 340110258B082
QGV 40/50/60Temp ProbeMicroprocessor2014000023
QR 340/350/370BeltsQR 350110258B083
QGV 40/50/60Temperature SwitchGauge-230F122880-232
QR 340/350/370BeltsQR 370110258B085
QGV 40/50/60Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QR 340/350/370Head Kit QR 340QR 340K340A
QGV 40/50/60Line Filter Kit129732-051
QR 340/350/370Head Kit QR 350QR 350K350G
QGV 40/50/60Min. Pressure Check Valve147564K
QR 340/350/370Head Kit QR 370QR 370K370A
QGV 40/50/60Transducer145072-1
QR 340/350/370Set of 4800# per pad, 3,200 for the set7802-1set
QGV 40/50/60Differential Pilot Valve Kit146175-100
QR 340/350/370Set of 41,200# per pad, 4,800 for the set7803-1set
QGV 40/50/60Transformer Fuse x 2Primary128857-011
QR 340/350/370Quincip ISO 68112542Q068
QGV 40/50/60Transformer Fuse Secondary128622-250
QR 340/350/370Quincip ISO 100112543Q100
QGV 75/100/125Oil Filter ElementSold by Case Only (12)142136CS
QR 390Air Filter110377E200
QGV 75/100/125Air Filter Element146397-10
QR 390Oil Filtersix pack110814-001
QGV 75/100/125Oil Separator 2 Required2013800404
QR 390BeltsQR 390110258B103
QGV 75/100/125Vent Filter Siemens G120144995-332
QR 390Valve Kit QR 390QR 390K390A
QGV 75/100/125Vent Filter TopSiemens Master Drive144995-152
QR 390Quincip ISO 68112542Q068
QGV 75/100/125Vent Filter BottomSiemens Master Drive144995-072
QR 390Quincip ISO 100112543Q100
QGV 75/100/125Temperature Switch230F122880-232
QR 5120Air Filter2 req.110377E200
QGV 75/100/125Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QR 5120Oil Filtersix pack110814-001
QGV 75/100/125Thermal Valve Kit(INCLUDES ELEMENT, SEAL & O-RING)125657-067
QR 5120BeltsQR 5120110258B120
QGV 75/100/125Min. Pressure Check Valve146342-050
QR 5120Valve Kit QR 5120QR 5120K5120A
QGV 75/100/125Transducer145072-1
QR 5120Set of 4800# per pad, 3,200 for the set7802-1set
QGV 75/100/125Drive panel Element144995-332
QR 5120Set of 41,200# per pad, 4,800 for the set7803-1set

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QSI 220/245Oil filter Sold by Case Only (6) 1999-Current142136cs
QSI 220/245Air filterJan 93-After23458-4
QSI 220/245Oil separator Jan 93-After2013402021
QSI 220/245Temp. Switch 225F- 2 required122880-222
QSI 220/245Temp. Switch 250F-2 required122880-252
QSI 220/245Temp. Switch240F122880-242
QSI 220/245Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSI 220/245Line Filter KitPilot Valve129731-050
QSI 220/245Line Filter KitUnload Solenoid143316-050
QSI 220/245Min Pressure Check Valve Kit128691-051
QSI 220/245Min Pressure Check Valve Kit128691-054
QSI 220/245Thermostatic Valve Kit124973-060
QSI 220/245Thermostatic Valve Kit124973-069 / 124973-070 / 124973-071124973-069 / 124973-070 / 124973-071
QSI 220/245Moisture Separator KitIncludes Gasket124827-052
QSI 220/245Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QSI 235Oil filter 1974-July 198222722-1
QSI 235Oil filter Heavy Duty23458-4
QSI 235Oil filter July 1982-June 1989124331-050
QSI 235Oil filter June 1989-After142136cs
QSI 235 Air filter1974-July 198223458-1
QSI 235 Air filterJuly 1982-Jan 1987125042-001
QSI 235 Air filterJan 1987-After127058E350
QSI 235Oil separator July 1982-After2013402008
QSI 235Line Filter Kit125049-001
QSI 235Oil filter Sold by Case Only (6) After 1/99142136cs
QSI 235 Air filterJan 93-After23458-4
QSI 235Oil separator 1/93-11/982013402021
QSI 235Temp. Switch x 2225F PLC- 2 required122880-222
QSI 235Temp. Switch240F Power Sync122880-242
QSI 235Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSI 235Line Filter KitPilot Valve129731-050
QSI 235Line Filter KitUnload Solenoid143316-050
QSI 235Min Pressure Check Valve Kit128691-051
QSI 235Thermostatic Valve Kit124973-060
QSI 235Moisture Separator KitIncludes Gasket124827-052
QSI 235Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QSI 335/370Oil filter Sold by Case Only (6)142136CS
QSI 335/370Air filterJan 1993-After23458-4
QSI 335/370Oil separator Jan 1993-After2013402009
QSI 335/370Temp. Switch x 2225F PLC- 2 required122880-222
QSI 335/370Temp. Switch x 2250F PLC-2 required122880-252
QSI 335/370Temp. Switch240F Power Sync122880-242
QSI 335/370Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSI 335/370Line Filter KitPilot Valve129731-050
QSI 335/370Line Filter KitUnload Solenoid143316-050
QSI 335/370Min Pressure Check Valve Kit128691-052
QSI 335/370Min Pressure Check Valve Kit128691-054
QSI 335/370Thermostatic Valve Kit124973-060
QSI 335/370Thermostatic Valve Kit124973-069
QSI 335/370Moisture Separator KitIncludes Gasket124827-052
QSI 335/370Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QSI 350Oil filter 1974-198322722-1
QSI 350Oil filter After June 1983124331-050
QSI 350Oil filter 1990 and after142136cs
QSI 350Air filter1974-June 198323458-4
QSI 350Air filter1987-After127058E350
QSI 350Oil separator 1974-19832013402042
QSI 350Oil separator June 1983-19902013402009
QSI 350Oil separator After 19902013402008
QSI 350Oil Seal22722-2
QSI 350Secondary separator2013402003
QSI 440/500Oil filter Sold by Case Only (6) 1/99-Current142136CS
QSI 440/500Air filter1993-March 199823458-2
QSI 440/500Air filter3/1/1998-200923458-5
QSI 440/500Air filter200923458-20
QSI 440/500Oil separator 1993-20092013402009
QSI 440/500Oil separator Nov 03-After2013402020
QSI 440/500Temp. Switch x 2225F PLC- 2 required122880-222
QSI 440/500Temp. Switch x 2250F PLC-2 required122880-252
QSI 440/500Temp. Switch240F Power Sync122880-242
QSI 440/500Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QSI 440/500Line Filter KitPilot Valve129731-050
QSI 440/500Line Filter KitUnload Solenoid143316-050
QSI 440/500Min Pressure Check Valve Kit128691-052
QSI 440/500Min Pressure Check Valve Kit128691-054
QSI 440/500Thermostatic Valve Kit124973-065
QSI 440/500Thermostatic Valve Kit124973-067
QSI 440/500Moisture Separator KitIncludes Gasket124827-052
QSI 440/500Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QSI 490Oil filter 1974-198522722-1
QSI 490Oil filter After 1985125656-050
QSI 490Oil filter After 1989142136cs
QSI 490Air filter1974-8523458-3
QSI 490Air filterAfter 1985125420E400
QSI 490Air filter12/1/1990-After127058E350
QSI 490Oil separator 2013402043
QSI 490Oil separator Secondary2013402004
QSI 490Oil separator After 19852013402009
QSI 490Line Filter KitPilot Valve125049-001
QSI 540/600Oil filter Sold by Case Only (6) After Jan 99142136CS
QSI 540/600Air filter10/10-Current23458-20
QSI 540/600Oil separator Oct 99-After124487-018
QSI 540/600Temp. Switch x 2225F PLC-2 required122880-232
QSI 540/600Temp. Switch240F Power Sync122880-242
QSI 540/600Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QSI 540/600Line Filter KitPilot Valve129731-050
QSI 540/600Line Filter KitUnload Solenoid143316-050
QSI 540/600Min Pressure Check Valve Kit128691-052
QSI 540/600Thermostatic Valve Kit124973-067
QSI 540/600Moisture Separator KitIncludes Gasket124827-052
QSI 540/600Diff Pilot Valve KitDiaphragm Assembly/Seat20775
QSI 675/750Oil Filter750 HP 3/98 to current142243cs
QSI 675/750Oil filter x 2Sold by Case Only (6)142136CS
QSI 675/750Air filter750HP23458-5
QSI 675/750Air filter23458-18
QSI 675/750Oil separator 8/93-3/982013402044
QSI 675/750Oil separator 3/98-3/992013402046
QSI 675/750Oil separator March 99-After2013402010
QSI 675/750Temp. Switch x 2225F PLC- 2 required122880-232
QSI 675/750Temp. Switch240F Power Sync122880-242
QSI 675/750Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QSI 675/750Line Filter KitPilot Valve129731-050
QSI 675/750Line Filter KitUnload Solenoid143316-050
QSI 675/750Min Pressure Check Valve Kit128691-052
QSI 675/750Thermostatic Valve Kit124973-067
QSI 675/750Moisture Separator KitIncludes Gasket124827-052
QSI 675/750Diff Pilot Valve KitDiaphragm Assembly/Seat20775
QSI 740Oil FilterJan 1974-Sept 198922722-1
QSI 740Oil FilterSept 89-March 98142136cs
QSI 740 Air filter1974-198623458-4
QSI 740 Air filterAfter 198623458-5
QSI 740Oil separator Primary2013402044
QSI 740Oil separator Secondary2013402005
QSI 925/1000Oil filter x 2Sold by Case Only (6)142136CS
QSI 925/1000Oil filter x 21974-199522722-1
QSI 925/1000 Air filter1000- jan 1974-8/8423458-3
QSI 925/1000 Air filter10/86-present23458-5
QSI 925/1000Oil separator Primary2013402045
QSI 925/1000Oil separator Primary2013402021
QSI 925/1000Oil separator Secondary2013402006
QSI 925/1000Temp. Switch x 2Standard Unit-2 required122880-232
QSI 925/1000Temp. Switch240F Power Sync122880-242
QSI 925/1000Shaft Seal KitSlinger, Shaft Seal & Wear Ring141115
QSI 925/1000Line Filter KitPilot Valve129731-050
QSI 925/1000Line Filter KitUnload Solenoid143316-050
QSI 925/1000Min Pressure Check Valve Kit128691-052
QSI 925/1000Thermostatic Valve Kit(includes element, gasket & seal)22331-005
QSI 925/1000Moisture Separator KitIncludes Gasket124827-052
QSI 925/1000Diff Pilot Valve Kit-Power $yncDiaphragm Assembly/Seat20775
QSI 925/1000Diff Pilot Valve Kit-Standard UnitDiaphragm Assembly/Seat121904
QSI 1175/1250Oil filter- 2 requiredSold by Case Only (6) 1991-Current142243CS
QSI 1175/1250Oil filter- 2 required1974-199122722-1
QSI 1175/1250 Air filter1/74-8/8423458-3
QSI 1175/1250 Air filter8/84-present23458-5
QSI 1175/1250Oil separator Primary2013402046
QSI 1175/1250Oil separator Secondary2013402007
QSI 1175/1250Temp. Switch x 2Standard Unit- 2 required122880-232
QSI 1175/1250Temp. Switch240F Power Sync122880-242
QSI 1175/1250Shaft Seal KitSlinger, Shaft Seal & Wear Ring141115
QSI 1175/1250Line Filter KitPilot Valve129731-050
QSI 1175/1250Line Filter KitUnload Solenoid143316-050
QSI 1175/1250Min Pressure Check Valve Kit128691-053
QSI 1175/1250Thermostatic Valve Kit22331-005
QSI 1175/1250Moisture Separator KitIncludes Gasket124827-052
QSI 1175/1250Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QSI 1400/1500Oil filter- 2 requiredSold by Case Only (6) August 89-Current142243CS
QSI 1400/1500Oil filter- 2 required1500 1974 Early Element22722-1
QSI 1400/1500 Air filter23458-9
QSI 1400/1500 Air filter1974-11/8623458-3
QSI 1400/1500 Air filter11/86-200923458-5
QSI 1400/1500Oil separator Primary2013402046
QSI 1400/1500Oil separator Secondary2013402007
QSI 1400/1500Temp. Switch x 2Standard Unit- 2 required122880-232
QSI 1400/1500Temp. Switch240F Power Sync122880-242
QSI 1400/1500Shaft Seal KitSlinger, Shaft Seal & Wear Ring141115
QSI 1400/1500Line Filter KitPilot Valve129731-050
QSI 1400/1500Line Filter KitUnload Solenoid143316-050
QSI 1400/1500Min Pressure Check Valve Kit128691-053
QSI 1400/1500Thermostatic Valve KitElement, Gasket & Seal22331-005
QSI 1400/1500Moisture Separator KitIncludes Gasket124827-052
QSI 1400/1500Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100

QSIi

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QSIi 220/245Oil FilterSold by Case Only (6)142136CS
QSIi 220/245Air Filter146397-08
QSIi 220/245Oil Separator 2013800404
QSIi 220/245Temp. Switch 122880-232
QSIi 220/245Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSIi 220/245Min Pressure Check Valve Kit128691-051
QSIi 220/245Thermostatic Valve Kit124973-060
QSIi 220/245Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QSIi 250/300Oil filter Sold by Case Only (6)142136CS
QSIi 250/300Air Filter146397-08
QSIi 250/300Oil Separator 2013800404
QSIi 250/300Temp. Switch 122880-232
QSIi 250/300Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSIi 250/300Min Pressure Check Valve Kit128691-051
QSIi 250/300Thermostatic Valve Kit124973-060
QSIi 250/300Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QSIi 335/370Oil FilterSold by Case Only (6)142136CS
QSIi 335/370Air Filter146397-08
QSIi 335/370Oil separator 2013800404
QSIi 335/370Temp. Switch 122880-232
QSIi 335/370Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSIi 335/370Thermostatic Valve Kit125657-067
QSIi 335/370Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100
QSIi 440/500Oil FilterSold by Case Only (6)142136CS
QSIi 440/500Air Filter146397-10
QSIi 440/500Oil separator 2013800404
QSIi 440/500Temp. Switch 122880-232
QSIi 440/500Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QSIi 440/500Thermostatic Valve Kit125657-067
QSIi 440/500Diff Pilot Valve KitDiaphragm Assembly/Seat146175-100

QVG

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QGV 20/25/30Oil Filter ElementSold by Case Only (12)128598CS
QGV 20/25/30Air Filter Element128849E362
QGV 20/25/30Oil Separator Element2012100079
QGV 20/25/30Temp ProbeMicroprocessor2014000023
QGV 20/25/30Temperature SwitchGauge 230F122880-232
QGV 20/25/30Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QGV 20/25/30Line Filter Kit129732-051
QGV 20/25/30Min. Pressure Check Valve147564K
QGV 20/25/30Transducer145072-1
QGV 20/25/30Differential Pilot Valve Kit146175-100
QGV 20/25/30Transformer Fuse x 2Primary128857-011
QGV 20/25/30Transformer Fuse Secondary128622-250
QGV 40/50/60Oil Filter ElementSold by Case Only (12)142136CS
QGV 40/50/60Air Filter Element125420E200
QGV 40/50/60Oil Separator Element Kit2012100079
QGV 40/50/60Vent Filter Siemens G120144995-332
QGV 40/50/60Vent Filter TopSiemens Master Drive144995-152
QGV 40/50/60Vent Filter BottomSiemens Master Drive144995-072
QGV 40/50/60Temp ProbeMicroprocessor2014000023
QGV 40/50/60Temperature SwitchGauge-230F122880-232
QGV 40/50/60Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QGV 40/50/60Line Filter Kit129732-051
QGV 40/50/60Min. Pressure Check Valve147564K
QGV 40/50/60Transducer145072-1
QGV 40/50/60Differential Pilot Valve Kit146175-100
QGV 40/50/60Transformer Fuse x 2Primary128857-011
QGV 40/50/60Transformer Fuse Secondary128622-250
QGV 75/100/125Oil Filter ElementSold by Case Only (12)142136CS
QGV 75/100/125Air Filter Element146397-10
QGV 75/100/125Oil Separator 2 Required2013800404
QGV 75/100/125Vent Filter Siemens G120144995-332
QGV 75/100/125Vent Filter TopSiemens Master Drive144995-152
QGV 75/100/125Vent Filter BottomSiemens Master Drive144995-072
QGV 75/100/125Temperature Switch230F122880-232
QGV 75/100/125Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QGV 75/100/125Thermal Valve Kit(INCLUDES ELEMENT, SEAL & O-RING)125657-067
QGV 75/100/125Min. Pressure Check Valve146342-050
QGV 75/100/125Transducer145072-1
QGV 75/100/125Drive panel Element144995-332
QGV 150/200Oil Filter ElementSold by Case Only (12)142136CS
QGV 150/200Air Filter Element146397-12
QGV 150/200 Oil Separator 150 (3 Req) 200 (4 Req)2013800404
QGV 150/200Vent Filter TopSiemens Master Drive/G120144995-332
QGV 150/200Temperature Probe2014000023
QGV 150/200Temperature Switch230F122880-232
QGV 150/200Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QGV 150/200Min. Pressure Check Valve146342-050
QGV 150/200Transducer145072-1
QGV 150/200Drive panel Element144995-332
QGV 150/200Line Filter Kit129732-051
QGV 150/200Moisture Separator KitIncludes Gasket124827-052
QGV 150/200Air Regulator Kit23543-050

QMB

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QMB 10-30Oil Separator 2013402030
QMB 10-30Temp ProbeMicroprocessor-High Vibration143754
QMB 10-30Temperature SwitchGauge-225F122880s222
QMB 10-30Shaft Seal KitSlinger, Shaft Seal & Wear Ring129216
QMB 10-30Line Filter Kit(includes bowl seal, filter element, gasket)129732-051
QMB 10-30Min. Pressure Check Valve128813-050
QMB 10-30Transducer142133
QMB 10-30Differential Pilot Valve Kit(includes diaphragm assembly & seat)146175-100
QMB 10-30Moisture Sep. KitIncludes Gasket124827-052
QMB 10-30Oil Filter Sold by Case Only (12)128598CS
QMB 10-30Air Filter128849E362

QMA

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QMA 50/60Oil Filter Filters Sold by Case Only128381-050CS
QMA 50/60Air FilterHeavy Duty23458-1
QMA 50/60Oil Separator 2013402028
QMA 50/60Temperature Switch225F122880S222
QMA 50/60Shaft Seal KitSlinger, Shaft Seal & Wear Ring140517
QMA 50/60Line Filter Kit(includes bowl seal, filter element, gasket)129731-050
QMA 50/60Min. Pressure Check ValveWye Delta Units128691-051
QMA 50/60Differential Pilot Valve KitDiaphragm Assembly/Seat20775
QMA 50/60Moisture Sep. KitIncludes Gasket124827-052
QMA 75Oil Filter Filters Sold by Case Only142136CS
QMA 75Air FilterHeavy Duty23458-4
QMA 75Oil Separator 2013402026
QMA 75Temperature SwitchRequires 2122880S222
QMA 75Shaft Seal KitSlinger, Shaft Seal & Wear Ring140517
QMA 75Line Filter Kit(includes bowl seal, filter element, gasket)129731-050
QMA 75Min. Pressure Check Valve(wye-delta units)128691-052
QMA 75Differential Pilot Valve KitDiaphragm Assembly/Seat20775
QMA 75Moisture Sep. KitIncludes Gasket124827-052
QMA 100/125/150Oil Filter Sold by Case Only (12)128381-050CS
QMA 100/125/150Air Filter23458-5
QMA 100/125/150Oil Separator 2013402026
QMA 100/125/150Temperature Switch122880S222
QMA 100/125/150Temperature Switch122880-222
QMA 100/125/150Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QMA 100/125/150Min. Pressure Check Valve146342-050
QMA 100/125/150Kit-Diff Pilot ValveDiaphragm Assembly/Seat20775
QMA 100/125/150Line Filter Kit(includes bowl seal, filter element, gasket)129731-050
QMA 100/125/150Moisture Separator Kit(includes gasket)124827-052
QMA 100/125/150Timer 15 Minute122862-900
QMA 100/125/150Timer-15 SecondsWye-Delta Only122862-15
QMA 100/125/150RelayRequires 2125706-005
QMA 100/125/150O-Ring Viton22749-123
QMA 100/125/150Resevoir Top Plate128341
QMA 100/125/150Moisture Separator KitIncludes Gasket124827-051

QSLP

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QSLP 10/15/20 Oil Filter Sold by Case Only (6)128381-050CS
QSLP 10/15/20Air FilterHeavy Duty125420E300
QSLP 10/15/20 Oil Separator Primary127138-003
QSLP 10/15/20Oil SeparatorSecondary2013401998
QSLP 10/15/20Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSLP 30/60 Oil Filter Sold by Case Only (6)142136CS
QSLP 30/60Air Filter30HP23458-4
QSLP 30/60Air Filter60HP23458-2
QSLP 30/60Oil Separator 2013402018
QSLP 30/60Temperature SwitchPLC-Requires 2122880-232
QSLP 30/60Temperature SwitchPower Sync122880-242
QSLP 30/60Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSLP 30/60Line Filter Kit(includes bowl seal, filter element, gasket)129731-050
QSLP 30/60Line Filter Kit(includes bowl seal, filter element, gasket)143316-050
QSLP 30/60Min. Pressure Check Valve128691-058
QSLP 30/60Thermal Valve Kit125657-055
QSLP 30/60Moisture Sep. KitIncludes Gasket124827-052
QSLP 100Oil Filter Sold by Case Only (6)142136CS
QSLP 100Air Filter23458-5
QSLP 100 Oil Separator 2013402018
QSLP 100Temperature SwitchRequires 2122880-232
QSLP 100Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSLP 100Min. Pressure Check Valve128691-058
QSLP 100Kit-Diff Pilot ValveDiaphragm Assembly/Seat146175-100
QSLP 100Line Filter Kit(includes bowl seal, filter element, gasket)129731-050
QSLP 100Line Filter Kit(includes bowl seal, filter element, gasket)143316-050
QSLP 100Moisture Separator KitIncludes Gasket124827-052
QSLP 125Oil Filter Sold by Case Only (6)142136CS
QSLP 125Air Filter Requires 223458-5
QSLP 125 Oil Separator 2013402019
QSLP 125Temperature Switch122880-232
QSLP 125Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QSLP 125Min. Pressure Check Valve142566-050
QSLP 125Kit-Diff Pilot ValveDiaphragm Assembly/Seat20775
QSLP 125Line Filter Kit129731-050
QSLP 125Relay Flange Mounted Requires 2125706-005
QSLP 125Thermostatic Valve Kit(includes element, gasket,seal)125657-067
QSLP 125Moisture Separator KitIncludes Gasket124827-052
QSLP 150Oil Filter Sold by Case Only (6)142136CS
QSLP 150Air FilterRequires 223458-5
QSLP 150 Oil Separator 2013402019
QSLP 150Temperature Switch230F122880-232
QSLP 150Shaft Seal KitSlinger, Shaft Seal & Wear Ring140413
QSLP 150Min. Pressure Check Valve142566-050
QSLP 150Kit-Diff Pilot Valve(includes diaphragm,20775
QSLP 150Line Filter Kitdiaphragm gaskets, seat gasket, seat disk, seat ring)129731-050
QSLP 150Relay Flange Mounted Requires 2125706-005
QSLP 150Thermostatic Valve Kit(includes element, gasket, seal)125657-067
QSLP 150Moisture Separator KitIncludes Gasket124827-052
QSLP 200Oil Filter x 2Sold by Case Only (6)142136CS
QSLP 200Air Filter (Heavy Duty)23458-7
QSLP 200 Oil Separator Primary2013402041
QSLP 200 Oil Separator Secondary2013402002
QSLP 200Temperature SwitchRequires 2122880-232
QSLP 200Shaft Seal KitSlinger, Shaft Seal & Wear Ring141115
QSLP 200Min. Pressure Check Valve142566-050
QSLP 200Kit-Diff Pressure Regulator(includes diaphragm, gasket, seat gasket, seat disk, and seat ring)121904
QSLP 200Line Filter Kit129731-050
QSLP 200Relay Flange Mounted Requires 2125706-005
QSLP 200Thermostatic Valve Kit125657-067
QSLP 200Moisture Separator KitIncludes Gasket124827-052

QSVQSVB

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QSVB 7.5-25 Oil Filter Sold by Case Only (12)128381-050CS
QSVB 7.5-25 Air Filter141469-052
QSVB 7.5-25 Fluid StrainerCase Only141100-050CS
QSVB 7.5-25 Temperature122880-252
QSVB 7.5-25 Belt Set7.5 hp128085-360
QSVB 7.5-25 Belt Set10 hp128085-363
QSVB 7.5-25 Belt Set15 hp128085-356
QSVB 7.5-25 Belt Set20 hp128085-367
QSVB 7.5-25 Belt Set25 hp128085-360
QSVB 7.5-25 Timer-15 Minute122862-900
QSVB 7.5-25 Relay-Control2 Required125706-005
QSVB 7.5-25 Oil Separator 7.5-15 hp2013402032
QSVB 7.5-25 Oil Separator20 & 25 hp2013402033
QSVB 7.5-25 Shaft Seal KitSlinger, Shaft Seal & Wear Ring140209
QSVB 7.5-25 Inlet Valve Kit126865-050
QSVB 7.5-25 Thermostatic Valve7.5-15 hp128786-058
QSVB 7.5-25 Thermostatic Valve20 & 25 hp128786-056

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QSV 20/40Oil Filter Sold by Case Only (12)128381-050CS
QSV 20/40Inlet Filter ElementQSV 25hp141469-052
QSV 20/40Inlet Filter ElementQSV-40hp127357E004
QSV 20/40Temperature250F122880-252
QSV 20/40Oil Separator 2013402031
QSV 20/40Shaft Seal Kit140517
QSV 20/40Diff Pilot ValveDiaphragm Assembly/Seat146233-100

QSVi

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QSVi 25/40Oil Filter Sold by Case Only (12)128381-050CS
QSVi 25/40Inlet Filter Element25 hp141469-052
QSVi 25/40Inlet Filter Element40 hp127357E004
QSVi 25/40Oil Separator 2013402034
QSVi 25/40Shaft Seal Kit 40 HPSlinger, Shaft Seal & Wear Ring140517
QSVi 25/40Shaft Seal Kit 25 HPSlinger, Shaft Seal & Wear Ring140209
QSVi 25/40Diff Pilot Valve146233-100
QSVi 50Oil Filter Sold by Case Only (12)128381-050CS
QSVi 50Inlet Filter ElementRequires 2127357E005
QSVi 50TemperatureRequires 2122880-252
QSVi 50Oil Separator 2013402035
QSVi 50Element StrainerSold by Case Only141100-050CS
QSVi 50Thermostatic Valve128786-058
QSVi 75Oil Filter Sold by Case Only (12)142136CS
QSVi 75Inlet Filter ElementCall to Determine which Filter141469-052
QSVi 75Inlet Filter ElementCall to Determine which Filter127357E004
QSVi 75TemperatureRequires 2122880-252
QSVi 75Oil Separator 2013402036
QSVi 75Transformer x 21.5 AMP128857-004
QSVi 75Transformer x 24AMP128857-007
QSVi 75Fan Motor x 3128857-032
QSVi 75INCADESCANTAmber143144-01
QSVi 75INCADESCANTRed143144-02
QSVi 7515 Minute122862-900
QSVi 200Oil Filter x 2Sold by Case Only (6)142136CS
QSVi 200Air Filter Element23458-4
QSVi 200Oil Separator Primary2013402038
QSVi 200Oil Separator Secondary2013402039
QSVi 200Thermostatic Valve125657-060
QSVi 200Shaft Seal KitSlinger, Shaft Seal & Wear Ring141115
QSVi 200Thermal Valve Element125657-057
QSVi 200Thermal Valve Gasket125657-051
QSVi 200Thermal Valve Seal125657-052

QGB

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QGB 7.5-15VOil Filter 146513-1
QGB 7.5-15VAir Filter146515-1
QGB 7.5-15VSeparator146514-1
QGB 30-60Oil Filter Sold by Case Only (12)142136CS
QGB 30-60Air Filter Element146397-08
QGB 30-60 Oil Separator 2013800404
QGB 30-60Shaft Seal Kit140209
QGB 30-60Thermal Valve KitElement, Gasket & Seal124973-060
QGB 30-60Min. Pressure Check Valve Kit128691-051

QT

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QT54, QT5-QT 7.5Air FilterQT 5 & QT 7.5110377E100
QT54, QT5-QT 7.5Air FilterQT 54112845-06
QT54, QT5-QT 7.5BeltsQT54 and QT5110258B060
QT54, QT5-QT 7.5BeltsQT 7.5110258B061
QT54, QT5-QT 7.5Valve Kit QT54QT54 113047-001
QT54, QT5-QT 7.5Valve Kit QT5QT 5114096-002
QT54, QT5-QT 7.5Valve Kit QT7.5QT 7.5114419-001
QT54, QT5-QT 7.5Set of 4800# per pad, 3,200 for the set7802-1set
QT54, QT5-QT 7.5Set of 41,200# per pad, 4,800 for the set7803-1set
QT54, QT5-QT 7.5Quincip D115468Q
QT54, QT5-QT 7.5Quincip ISO 68112542Q068
QT54, QT5-QT 7.5Quincip ISO 100112543Q100
QT54, QT5-QT 7.5One Year Maintenance KitQT54114325-015
QT54, QT5-QT 7.5One Year Maintenance KitQT5/7.5114325-008
QT 10-15Air FilterQt 15- Requires 2110377E100
QT 10-15BeltsQT10110258B082
QT 10-15BeltsQT 15110258B098
QT 10-15Valve Kit QT10 LPQT10 116162K1
QT 10-15Valve Kit QT10 HPQT10116163K1
QT 10-15Valve Kit QT15 – LPQT 15 – 2 req112713M15
QT 10-15Valve Kit Qt 15 – HPQT 15 – 2 req112714
QT 10-15Set of 4800# per pad, 3,200 for the set7802-1set
QT 10-15Set of 41,200# per pad, 4,800 for the set7803-1set
QT 10-15Quincip D115468Q
QT 10-15Quincip ISO 68112542Q068
QT 10-15Quincip ISO 100112543Q100
QT 10-15One Year Maintenance KitQT 10114325-011
QT 10-15One Year Maintenance KitQT 15114325-009
QT 30Air FilterQT30-REQUIRES 2110377E100
QT 30Belts20 HP110258B116
QT 30Belts25/30 HP 100psi110258B120
QT 30Set of 4800# per pad, 3,200 for the set7802-1set
QT 30Set of 41,200# per pad, 4,800 for the set7803-1set
QT 30Quincip D115468Q
QT 30Quincip ISO 68112542Q068
QT 30Quincip ISO 100112543Q100
QT 30One Year Maintenance KitQT 30114325-019

QR

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QR 310/325Air Filter110377E100
QR 310/325Oil Filtersix pack110814-001
QR 310/325BeltsQR 310110258B057
QR 310/325BeltsQR 325110258B068
QR 310/325Head Kit QR 310QR 310K310A
QR 310/325Head Kit QR 325QR 325K325A
QR 310/325Set of 4800# per pad, 3,200 for the set7802-1set
QR 310/325Set of 41,200# per pad, 4,800 for the set7803-1set
QR 310/325Quincip ISO 68112542Q068
QR 310/325Quincip ISO 100112543Q100
QR 340/350/370Air Filter110377E200
QR 340/350/370Oil Filter6 pack110814-001
QR 340/350/370BeltsQR 340110258B082
QR 340/350/370BeltsQR 350110258B083
QR 340/350/370BeltsQR 370110258B085
QR 340/350/370Head Kit QR 340QR 340K340A
QR 340/350/370Head Kit QR 350QR 350K350G
QR 340/350/370Head Kit QR 370QR 370K370A
QR 340/350/370Set of 4800# per pad, 3,200 for the set7802-1set
QR 340/350/370Set of 41,200# per pad, 4,800 for the set7803-1set
QR 340/350/370Quincip ISO 68112542Q068
QR 340/350/370Quincip ISO 100112543Q100
QR 390Air Filter110377E200
QR 390Oil Filtersix pack110814-001
QR 390BeltsQR 390110258B103
QR 390Valve Kit QR 390QR 390K390A
QR 390Quincip ISO 68112542Q068
QR 390Quincip ISO 100112543Q100
QR 5120Air Filter2 req.110377E200
QR 5120Oil Filtersix pack110814-001
QR 5120BeltsQR 5120110258B120
QR 5120Valve Kit QR 5120QR 5120K5120A
QR 5120Set of 4800# per pad, 3,200 for the set7802-1set
QR 5120Set of 41,200# per pad, 4,800 for the set7803-1set
QR 5120Quincip ISO 68112542Q068
QR 5120Quincip ISO 100112543Q100

QP

TIP* Use the search bar to filter the table by any term! Example, Air will bring up all parts containing “Air” or 2013 will bring up all part numbers containing “2013”

ModelPartSpecificsPart Number
QP 5/7.5QP 5 Minor KitAir Filter/Quincip D2022103400
QP 5/7.5QP 7.5 Minor KitAir Filter/Quincip D2022103400
QP 10/15Air Filter110377E100
QP 10/15Oil Filter110814-001
QP 10/15BeltsQP 10110258B082
QP 10/15BeltsQP 15110258B098
QP 10/15Valve Kit QT5QP 10KQT10H
QP 10/15Valve Kit QT7.5QP 15KQT15B
QP 10/15Ring KitQP10 LP116176
QP 10/15Ring KitQP10 HP116177
QP 10/15Ring KitQP15 LP8161
QP 10/15Ring KitQP15 HP8166
QP 10/15Vibration Pads800# per pad, 3,200 for the set7802-1set
QP 10/15Vibration Pads1,200# per pad, 4,800 for the set7803-1set
QP 10/15Quincip DQP-10 reqs 4 with the filter, QP-15 reqs 5 with the filter115468Q
QP 10/15QP 10 Minor KitAir Filter/Quincip D2022103500
QP 10/15QP 15 Minor KitAir Filter/Quincip D2022103600
QP 5/7.5Air Filter110377E100
QP 5/7.5Oil FilterSix Pack110814-001
QP 5/7.5BeltsQP 5110258B060
QP 5/7.5BeltsQP 7.5110258B061
QP 5/7.5Valve Kit QT5QP 5KQT5A
QP 5/7.5Valve Kit QT7.5QP 7.5KQT75HA
QP 5/7.5Ring KitQP 5 LP111199
QP 5/7.5Ring KitQP 5 HP111200
QP 5/7.5Ring KitQP 7.5 LP114209
QP 5/7.5Ring KitQP 7.5 HP114210
QP 5/7.5Vibration Pads800# per pad, 3,200 for the set7802-1set
QP 5/7.5Vibration Pads1,200# per pad, 4,800 for the set7803-1set
QP 5/7.5Quincip DQuart- REQUIRES 2115468Q

Fast, Friendly Response

We offer a search by part number to find the Quincy compressor parts you need knowing that the part you select is the correct part. If you can’t find the Quincy part online, feel free to call our responsive customer service department at 888-727-8714 and we will find the correct Quincy compressor parts your machine requires. Compressor Now is here to offer competitive prices on parts, filters and lubricants all while maintaining a high level of customer service and a fast turnaround.

OEM & Replacement Air Compressor Parts

From air inlet to water separators we either will have it on hand or we can find it for you. Downtime is detrimental to your business and we understand how important your air compressor is your business operations. That is why we go out of our way to make sure that all parts whether you choose OEM or replacement parts are delivered to you as quickly as possible and of course if it is regular service parts you are looking for get set up on our contract free plan that is specifically tailored to your business and falls in line with the Quincy recommended service intervals.

Quincy Parts, Filters and Lubricants

Search All Quincy Parts Here

You've just added this product to the cart:
